RELIABILITY PERFORMANCE
Reliability Experiment For Electrical
Test Item
Test Condition
Standard Source
MIL-STD-202G
Method 103B
Test Condition B
+40℃± 2℃, humidity of 90% ± 5% (total 96 hours).
Humidity Test
1.Temperature: +125℃±2℃
2.Test time: 48±2hrs
High Temperature
Test
IEC 68-2
Test Condition B
1.Temperature: -40℃±2℃
2.Test time: 48±2hrs
Low Temperature
Test
IEC 68-2
Test Condition A
MIL-STD-202G
Method 107G
Test Condition B-
2
+125℃±5℃ (30 minutes) ~ -40 ± 5℃ (30 minutes),
temperature switch time: 5 minutes (total 50 cycles).
Thermal Shock
Life Test
MIL-STD-202G
Method 108A
Test Condition B
+70℃±5℃ (250Hours)
Reliability Experiment For Physical
Test Item
Test Condition
Standard Source
10-55-10HZ, amplitude: 1.5mm, direction: X, Y, Z axes, MIL-STD-202G
Vibration Test
each axis 2 hours (total 6 hours).
Method 201A
IR/convection reflow:Peak Temp 250±5℃ for 5Sec in
air, Through 2 Cycle. Temperature
Ramp:+1~4°C/sec; Above1 83°C, must keep 90 s - 120
s
MIL-STD-202G
Method 210F
Test Condition
(Reflow)
Solder Heat
Resistance Test
Soak in 245 ℃ solder pot of 3Sec, PAD must have
95% above coverage.
Solder Ability Test
J-STD-003B
