WTC2172
ELECTRICAL CHARACTERISTICS (T =25 C unless otherwise noted) (Countinued)
A
Characteristics
Symbol
Min
Typ
Unit
Max
ON CHARACTERISTICS
DC Current Gain
(I = 2 mAdc, V = 6.0 Vdc)
-
70
h
-
700
FE
C
CE
Collector-Emitter Saturation Voltage
(I = 100 mAdc, I = 10mAdc)
V
-
Vdc
0.25
CE(sat)
Cob
0.1
C
B
Output Capacitance
PF
-
2.0
-
3.5
(V =10Vdc, I =0A, f=1MHZ)
CB
E
Transition Frequency
(I = 1 mAdc, V =10 Vdc)
f
T
MHz
80
-
C
CE
CLASSIFICATION OF h
FE
O
Rank
BL
Y
120-240
LY
GR
Range
70-140
LO
350-700
LL
200-400
LG
Marking
WEITRON
