IC25
VCES
= 6 A
= 1200 V
IGBT Module
Sixpack in ECO-PAC 2
VWI 6-12P1
VCE(sat)typ. = 3.9 V
S9
K12
Preliminary data
NTC
X18
N 9
R 5
L9
N 5
J13
W 14
A5
D 5
H 5
A1
F 3
C 1
K10
G 1
Pinarrangementseeoutlines
Features
IGBTs
• NPT IGBT's
Symbol
VCES
Conditions
Maximum Ratings
- positive temperature coefficient of
saturation voltage
- fast switching
TVJ = 25°C to 150°C
1200
V
V
±
VGES
20
• FRED diodes
- fast reverse recovery
- low forward voltage
IC25
IC80
TC = 25°C
TC = 80°C
6
4.1
A
A
• Industry Standard Package
- solderable pins for PCB mounting
- isolated DCB ceramic base plate
ICM
VCEK
VGE = 15/0 V; R = 89 Ω; TVJ = 125°C
9.6
VCES
A
µs
W
RBSOA, ClampGed inductive load; L = 100 µH
tSC
(SCSOA)
VCE = VCES; VGE = 15/0 V; RG = 89 Ω; TVJ = 125°C
non-repetitive
10
TypicalApplications
Ptot
TC = 25°C
40
• AC drives
• power supplies with power factor
correction
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min.
typ. max.
VCE(sat)
IC = 4 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
3.9
4.6
4.6
V
V
VGE(th)
ICES
IC = 0.1 mA; VGE = VCE
3
5
V
VCE = VCES
;
VGE = 0 V; TVJ = 25°C
0.1 mA
mA
VCE = 960 V; VGE = 0 V; TVJ = 125°C
0.5
±
IGES
VCE = 0 V; VGE
=
20 V
100 nA
td(on)
tr
td(off)
tf
Eon
Eoff
30
20
290
90
0.4
0.2
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 600 V; IC = 4 A
VGE = 15/0 V; RG = 89 Ω
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 960 V; VGE = 15 V; IC = 2 A
205
11
pF
nC
RthJC
RthJH
(per IGBT)
(per IGBT) with heatsink compound
3.1 K/W
K/W
6.2
IXYS reserves the right to change limits, test conditions and dimensions.
© 2003 IXYS All rights reserved
1 - 2
