VWI 35-06P1
IC25
VCES
= 31 A
= 600 V
IGBT Module
Sixpack in ECO-PAC 2
VCE(sat)typ. = 1.9 V
S9
N 9
X18
L9
N 5
R 5
W 14
A5
D 5
H 5
C 1
K10
A1
Pinarangementseeoutlines
F 3
G 1
Features
IGBTs
• NPT IGBT's
Symbol
VCES
Conditions
Maximum Ratings
- positive temperature coefficient of
saturation voltage
- fast switching
TVJ = 25°C to 150°C
600
V
V
±
VGES
20
• FRED diodes
- fast reverse recovery
- low forward voltage
IC25
IC80
TC = 25°C
TC = 80°C
31
21
A
A
• Industry Standard Package
- solderable pins for PCB mounting
- isolated DCB ceramic base plate
ICM
VCEK
VGE = ±15 V; RG = 47 Ω; TVJ = 125°C
RBSOA, Clamped inductive load; L = 100 µH
40
VCES
A
µs
W
tSC
(SCSOA)
VCE = 600 V; VGE = ±15 V; RG = 47 Ω; TVJ = 125°C
non-repetitive
10
TypicalApplications
Ptot
TC = 25°C
100
• AC drives
• power supplies with power factor
correction
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min.
typ. max.
VCE(sat)
IC = 20 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
1.9
2.2
2.4
V
V
VGE(th)
ICES
IC = 0.5 mA; VGE = VCE
4.5
6.5
V
VCE = VCES
;
VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.6 mA
mA
0.7
±
IGES
VCE = 0 V; VGE
=
20 V
100 nA
td(on)
tr
td(off)
tf
Eon
Eoff
50
55
300
30
0.9
0.7
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 300 V; IC = 10 A
VGE = ±15 V; RG = 82 Ω
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 300 V; VGE = 15 V; IC = 20 A
1100
65
pF
nC
RthJC
RthJH
(per IGBT)
with heatsink compound (0.42 K/m.K; 50 µm)
1.3 K/W
K/W
2.5
IXYS reserves the right to change limits, test conditions and dimensions.
© 2003 IXYS All rights reserved
1 - 5
