VUE 75-12NO7
ECO-PAC TM
Threee Phase Rectifier Bridge
with Fast Recovery Epitaxial Diodes (FRED)
IdAV = 74 A
VRRM = 1200 V
trr
= 40 ns
D
VRSM
V
VRRM
V
Typ
A
H
N
1200
1200
VUE 75-12NO7
K
Symbol
Conditions
Maximum Ratings
Features
• Package with DCB ceramic
base plate in low profile
• Isolation voltage 3000 V~
• Planar passivated chips
• Low forward voltage drop
• Leads suitable for PC board soldering
IdAV
IdAVM
①
TC = 85°C, module
74
90
A
A
IFSM
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
200
220
A
A
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
170
190
A
A
Applications
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
200
205
A2s
A2s
• Supplies for DC power equipment
• Input and output rectifiers for high
frequency
• Battery DC power supplies
• Field supply for DC motors
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
145
150
A2s
A2s
TVJ
TVJM
Tstg
-40...+150
150
-40...+125
°C
°C
°C
Advantages
• Space and weight savings
• Improved temperature and power
cycling capability
VISOL
50/60 Hz, RMS t = 1 min
IISOL £ 1 mA t = 1 s
3000
3600
V~
V~
• Small and light weight
• Low noise switching
Md
Weight
Mounting torque (M4)
typ.
1.5-2/14-18 Nm/lb.in.
19
g
Dimensions in mm (1 mm = 0.0394")
Symbol
IR
Conditions
Characteristic Values
typ.
max.
VR = VRRM
VR = VRRM
TVJ = 25°C
TVJ = TVJM
0.25 mA
1.0 mA
VF
IF = 30 A
TVJ = 25°C
2.71
V
VT0
rT
for power-loss calculations only
1.31
15 mW
V
RthJC
RthCH
per diode; DC current
per diode, DC current, typ.
0.9 K/W
0.3 K/W
IRM
trr
IF = 50 A, -diF/dt = 100 A/µs
VR = 100 V, L = 0.05 mH, TVJ = 100°C
IF = 1 A; -di/dt = 200 A/µs; VR = 30 V, TVJ = 25°C
6
11.4
A
40
tbd ns
a
dS
dA
Max. allowable acceleration
creeping distance on surface
creepage distance in air
50
11.2
9.7
m/s2
mm
mm
Data according to IEC 60747 refer to a single diode unless otherwise stated
for resistive load at bridge output.
①
IXYS reserves the right to change limits, test conditions and dimensions.
© 2000 IXYS All rights reserved
1 - 2
