VUE 30
IdAV = 30 A
VRRM = 2000 V
Three Phase
Rectifier Bridge
with Fast Recovery Epitaxial Diodes (FRED)
trr
= 70 ns
Preliminary data
5
+
–
VRSM
V
VRRM
V
Type
1
~
~
~
2000
2000
VUE 30-20NO1
10
8
6
Symbol
IdAV
Conditions
TC = 65°C, module
Maximum Ratings
Features
●
Package with DCB ceramic base plate
Isolation voltage 3600 V~
Planar passivated chips
Leads suitable for PC board soldering
Creeping and creepage-distance
fulfil UL 508/CSA 22.2NO14 and
VDE 0160 requirements
Epoxy meets UL94V-O
UL registered E72873
30
75
A
●
●
●
●
IFSM
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
A
T
VJ = TVJM
t = 10 ms (50 Hz), sine
t = 10 ms (50 Hz), sine
t = 10 ms (50 Hz), sine
65
A
VR = 0
I2dt
TVJ = 45°C
VR = 0
28
21
A2s
A2s
●
●
TVJ = TVJM
VR = 0
Applications
●
Supplies for DC power equipment
Input rectifiers for PWM inverter
Output filter for PWM inverter
●
TVJ
TVJM
Tstg
-40...+150
150
-40...+125
°C
°C
°C
●
Advantages
VISOL
50/60 Hz, RMS t = 1 min
IISOL £ 1 mA t = 1 s
3000
3600
V~
V~
●
Reduced EMI/RFI
Easy to mount with two screws
Space and weight savings
●
Md
Mounting torque (M5)
(10-32UNF)
2 - 2.5
18 - 22
Nm
lb.in.
●
●
Improved temperature and power
cycling
Weight
typ.
35
g
Dimensions in mm (1 mm = 0.0394")
Symbol
IR
Conditions
Characteristic Values
typ.
max
VR = VRRM
VR = 0.8 VRRM
TVJ = 25°C
TVJ = 125°C
0.75
7
mA
mA
4
VF
IF = 12 A
TVJ = 25°C
5.41
V
VT0
rT
For power-loss calculations only
3.3
93
V
mW
RthJC
RthCH
per diode,
DC
1.7
K/W
K/W
0.3
9
IRM
trr
IF = 12 A, -diF/dt = 100 A/ms
VR = 540 V, L £ 0.05 mH, TVJ = 100°C
IF = 1 A; -di/dt = 100 A/ms; VR = 30 V, TVJ = 25°C
12
90
A
70
ns
dS
dA
a
Creeping distance on surface
Creepage distance in air
Max. allowable acceleration
12.7
9.4
50
mm
mm
m/s2
Data according to IEC 60747 and refer to a single diode unless otherwise stated.
© 2000 IXYS All rights reserved
1 - 1
