WTF16A60H
Bi-Directional Triode Thyristor
Features
■ Repetitive Peak off-State Voltage: 600V
■ R.M.S On-State Current(IT(RMS)=16A)
■ Isolation Voltage ( VISO = 1500V AC )
■ High Commutation dV/dt.
■ High Junction temperature(TJ=150℃)
General Description
Winsemi Triac WTF16A60H is designed for full wave AC control applications.
It can be used as an ON/OFF function or for phase control operation.
By using an internal ceramic pad, the TO220F series provides voltage
insulated tab (rated at 2500V RMS) complying with UL standards (file
ref.:E347423)
Typical Application
■ Home Appliances : Washing Machines, Vacuum Cleaners, Rice
Cookers, Micro Wave Ovens, Hair Dryers, other
control applications
A1
A2
G
TO220F
■ Industrial Use :
SMPS, Copier Machines, Motor Controls,
Dimmer, SSR, Heater Controls, Vending Machines,
other control applications
Absolute Maximum Ratings (Tj=25℃ unless otherwise specified)
Symbol
Parameter
Condition
Ratings Units
V
Repetitive Peak Off-State Voltage
600
V
DRM/VRRM
T = 1118 °C
I
R.M.S On-State Current
Surge On-State Current
16
A
A
J
T(RMS)
50/60Hz, One cycle, Peak value, non-repetitive
I
155/170
TSM
I2t
2
2
120
5
I t
A s
P
Peak Gate Power Dissipation
Average Gate Power Dissipation
Peak Gate Current
W
W
A
GM
P
0.5
G(AV)
I
2.0
GM
V
Peak Gate Voltage
7.0
V
GM
T
Operating Junction Temperature
Storage Temperature
-40~+150
-40~+150
℃
℃
J
T
STG
Thermal Characteristics
Symbol
Value
Typ
Parameter
Units
Min
-
Max
3
RQJC
RQJA
Thermal resistance, Junction-to-Case
Thermal resistance, Junction-to-Ambient
-
℃/W
℃/W
-
-
150
