WTPA16A60CW
Bi-Directional Triode Thyristor
Features
■ Repetitive Peak off-State Voltage: 600V
■ R.M.S On-State Current(IT(RMS)=16A
■ Low on-state voltage: VTM=1.55V(Max.)@ IT=22.5A
■ High Commutation dV/dt.
Tab
General Description
General purpose swithhing and phase control applications. These
devices are intended to be interfaced directly to micro-controllers,
logic integrated circuits and other low power gate trigger circuits
such as fan speed and temperature modulation control, lighting
control and static switching relay.
The -W series are specially recommended for use on inductive loads,
thanks to their high commutation performances. By using an internal
ceramic pad, the WTPA series provides voltage insulated tab (rated
at 2500V RMS). complying with UL standards (file ref.:E347423)
TO220ISO
Absolute Maximum Ratings (TJ=25℃ unless otherwise specified)
Symbol
VDRM/VPRM
IT(RMS)
Parameter
Value
Units
Peak Repetitive Forward Blocking Voltage(gate open) (Note 1)
600
V
Forward Current RMS (All Conduction Angles, TJ=58℃)
16
A
ITSM
I2t
Peak Forward Surge Current, (full Cycle, Sine Wave, 50/60 Hz)
Circuit Fusing Considerations (tp= 10 ms)
160/168
A
A2s
W
144
5
PGM
PG(AV)
Peak Gate Power — Forward, (TJ = 58°C,Pulse with≤1.0us)
Average Gate Power — Forward, (Over any 20ms period)
1
W
Critical rate of rise of on-state current
TJ=125℃
dI/dt
50
A/μs
ITM = 20A; IG = 200mA; dIG/dt = 200mA/µs
IFGM
VRGM
TJ,
Peak Gate Current — Forward, TJ = 125°C (20 µs, 120 PPS)
Peak Gate Voltage — Reverse, TJ= 125°C (20 µs, 120 PPS)
Junction Temperature
4
A
V
10
-40~125
-40~150
℃
℃
Tstg
Storage Temperature
Note1: .Although not recommended, off-state voltages up to 800V may be applied without damage, but the TRIAC may
swiTJh to the on-state. The rate of rise of current should not exceed 15A/us.
Thermal Characteristics
Value
Typ
Symbol
Parameter
Units
Min
Max
RQJC
RQJA
Thermal Resistance, Junction-to-Case
Thermal Resistance, Junction-to-Ambient
-
-
1.6
℃/W
℃/W
-
-
60
Rev. A Sep.2010
T03-3
