Common mode Noise Filter Array
Common mode Noise Filter Array
Type:
EXC28CG
■ Features
● 2 Common mode noise filters in one package
● Small size and low-profile(L 2.0 mmꢀW 1.0 mmꢀH 0.5 mm)
● The 3 GHz or wider signal pass band prevents rounding of transmitted signal waveforms.
● The TDR value is controlled to 100 ꢁ (typ.), preventing transmission signal reflection
● The filter passed the HDMI eye pattern test, and was improved against jitters, phase shifting, and other waveform
deformations.
● Reduce the common mode noise and reform the signal wave by high-coupled inductors
● Magnetic shield type
■ Recommended Applications
● HDMI data lines such as TV, STB, DVD, DVC.
● S-ATA data lines such as PCs , HDD.
■ Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
X
C
2
8
C
G
9
0
0
U
Product Code
Size
Number of Type Characteristics
Terminals
Nominal Impedance
Form
Suffix
Coupled
type
The first two digits are
significant figure of
impedance value, and the
third one denotes the
number of zeros following
High speed
Differential transmission
(for Gbps)
Code Dimensions(mm)
Code
Packing
8 Terminals
C
Noise Filter
G
2.0 ꢀ 1.0 ꢀ 0.5
U
Embossed Carrier Taping
2
(L) ꢀ (W) ꢀ (H)
■ Construction
■ Dimensions in mm (not to scale)
F
D
E
Ferrite
C
A
B
Mass
Dimensions (mm)
Type
(Weight)
Inner Conductor
Electrode
(inches)
A
B
C
D
E
F
[mg/pc.]
EXC28CG
(0804)
1.00 0.15 2.0 0.2
0.5 0.1 0.20 0.15 0.5 0.1 0.25 0.10 5
■ Circuit Configuration
8
7
6
5
8
7
6
5
1
2
3
4
1
2
3
4
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Mar. 2010
