Common mode Noise Filters
Common mode Noise Filters
Type:
EXC24CE
EXC24CF
■ Features
■ Recommended Applications
● USB data lines such as PCs, DSC, Mobile phone.
● Reduce the common mode noise and reform the signal
wave by high-coupled inductors
● LVDS data lines such as PCs, TV.
● The strong multi-layer structure provides high resistance
to reflow soldering heat and a high mounting reliability
● Magnetic shield type
● IEEE1394 data lines such as PCs, TV.
● High-Q impedance : EXC24CF type is also available
● Small size and low-profile
×
×
(L 1.25 mm W 1.00 mm H 0.50 mm)
● RoHS compliant
■ Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
&
9
$
ꢀ
ꢁ
$
&
ꢂ
ꢃ
ꢃ
6
Product Code
Size
Number of Type Characteristics
Terminals
Nominal Impedance
Form
Suffix
Coupled
type
The first two digits are
significant figure of
impedance value, and the
third one denotes the
number of zeros following
High speed
Differential transmission
(for Mbps)
High speed
Differential transmission
(for Mbps) High-Q type
Code Dimensions(mm)
Code
U
Packing
4 Terminals
C
Noise Filter
E
F
Embossed Carrier Taping
4 mm pitch, 5,000 pcs.
1.25 L 1.00 L 0.50
2
(L) L (W) L (H)
■ Construction
■ Dimensions in mm (not to scale)
F
Ferrite
C
D
E
A
B
Electrode
Mass
Dimensions (mm)
Type
Inner Conductor
(Weight)
[mg/pc.]
(inch size)
A
B
C
D
E
F
EXC24CE/CF
(0504)
1.25 0.15 1.00 0.15 0.50 0.10 0.20 0.15 0.55 0.10 0.30 0.10
3
■ Circuit Configuration(No Polarity)
4
3
4
3
1
2
1
2
✽The pin numbers shown here are for reference purposes
only. Confirm the actual pin number arrangement with
the exchanged specification documents.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
