applications
OV2640
¬ cell and camera phones
¬ toys
¬ PC multimedia
¬ digital still cameras
ordering information
¬ OV02640-VL9A
(color, CSP2-38)
product features
¬ high sensitivity for low-light
operation
¬ automatic image control
functions including automatic
exposure control (AEC),
automatic gain control (AGC),
automatic white balance (AWB),
automatic band filter (ABF), and
automatic black-level
product specifications
¬ embedded compression engine
supporting most common
compression formats
¬ array size: 1600 x 1200 (UXGA)
¬ sensitivity: 0.6 V/Lux-sec
¬ S/N ratio: 40 dB
¬ power supply
core: 1.3VDC 5ꢀ
analog: 2.5 ~ 3.0VDC
I/O: 1.7V to 3.3V
¬ dynamic range: 50 dB
¬ pixel size: 2.2 μm x 2.2 μm
¬ dark current: 15 mV/s at 60°C
¬ well capacity: 12 Ke
¬ output support for Raw RGB, RGB
(RGB565/555), GRB422, YUV
(422/420) and YCbCr (4:2:2)
formats
calibration (ABLC)
¬ image quality controls including
color saturation, gamma,
sharpness (edge enhancement),
lens correction, white pixel
canceling, noise canceling,
¬ power consumption
active (full resolution)
¬ supports image sizes: UXGA,
SXGA, SVGA, and any size scaling
down from SXGA to 40x30
125 mW (for 15 fps, YUV mode)
140 mW (for 15 fps, compressed mode)
¬ fixed pattern noise:
<1ꢀ of VPEAK-TO-PEAK
standby: 600μA
50/60 Hz luminance detection
and variable frame rate control
¬ VarioPixel® for increased
sensitivity when sub-sampling
¬ lens size: 1/4"
¬ image area:
3590 μm x 2684 μm
¬ maximum image transfer rate
¬ package dimensions:
5725 μm x 6285 μm
UXGA/SXGA: 15 fps
SVGA: 30 fps
CIF: 60 fps
block diagram
OmniVision reserves the right to make changes to their products or to discontinue
any product or service without further notice. ‘OmniVision’, the OmniVision logo,
‘VarioPixel,’ and ‘OmniPixel’ are registered trademarks of OmniVision Technology. All
other trademarks are the property of their respective owners.
1341 Orleans Drive
Sunnyvale, CA 94089
USA
tel: + 1 408 542 3000
fax: + 1 408 542 3001
www.ovt.com
Version 1.8:2.4, May, 2006
