Applications
OV24A10
¬
Smartphones
¬
PC Multimedia
¬
Video Conferencing
Ordering Information
¬
¬
¬
OV24A10-GA5A-Z
Product Features
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
OV24A1B-GA5A-Z
(B&W, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
¬
automatic black level calibration (ABLC)
¬
¬
programmable I/O drive capability
¬
programmable controls for:
- frame rate
gyro interface
with 3-/4-wire SPI support
OV24A1Q-GA5A-Z
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
- mirror and flip
- binning
- cropping
- windowing
¬
¬
embedded 16k bits of one-time
programmable (OTP) memory
(4k bits reserved for customer use)
¬
¬
support for dynamic DPC cancellation
4-cell support
(OV24A1Q without PDAF):
- 4-cell binning
- 4-cell full
- 4-cell HDR timing
Product Specifications
supports output formats:
- 10-bit RGB RAW
- DPCM 10-8 compression
¬
active array size: 5664 x 4248
¬
maximum image transfer rate:
- 5664 x 4248: 30 fps
- 3840 x 2160: 60 fps
- 1920 x 1080: 120 fps
- 1280 x 720: 240 fps
¬
power supply:
- core: 1.05V
- analog: 2.8V
- I/O: 1.8V
¬
¬
supports horizontal and
vertical subsampling
¬
¬
sequential multi-frame HDR
(OV24A10/OV24A1B)
supports typical images sizes:
- 5664 x 4248
ZigZag HDR timing
(OV24A10/OV24A1B)
¬
¬
¬
maximum exposure: VTS - 14 lines
minimum exposure: 8 lines
sensitivity:
¬
¬
power requirements:
- active: 390 mW
- XSHUTDOWN: <1.5 µW
- 3840 x 2160
- 1920 x 1080
¬
¬
¬
¬
three on-chip phase lock loops (PLLs)
programmable I/O drive capability
built-in temperature sensor
- 1280 x 720
-
temperature range:
- operating: -30°C to +85°C junction
temperature
- stable: 0°C to +60°C junction
temperature
- OV24A10: 2700 e /Lux-sec
¬
¬
standard serial SCCB interface
-
- OV24A1B: 3000 e /Lux-sec
up to 4-lane MIPI TX interface
with speed up to 2.5 Gbps/lane
¬
¬
¬
¬
¬
¬
max S/N ratio: 35.7 dB
typical module size: 8.5 x 8.5 x ~5.5 mm
dynamic range: 71.0 dB @ 16x gain
scan mode: progressive
¬
output formats:
- 10-bit RGB RAW
- DPCM 10-8 compression
pixel size: 0.9 µm x 0.9 µm
image area: 5112 µm x 3852 µm
¬
¬
¬
lens size: 1/2.83"
lens chief ray angle: 35.1° non-linear
input clock frequency: 6 ~ 27 MHz
dimensions:
- COB: 6148.8 µm x 4406.4 µm
- RW: 6198.8 µm x 4456.4 µm
Functional Block Diagram
OV24A10
image sensor core
sensor
processor
interface
column
sample/hold
MCP/N
MDP/N[3:0]
array
10-bit
ADC
AMP
temperature
sensor
gain
control
control register bank
SCCB interface
timing generator and
system control logic
PLLs PLL
