Applications
OV20880
¬ Smartphones
¬ PC Multimedia
¬ Video Conferencing
Ordering Information
¬
OV20880-GA5A
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
Product Features
¬ automatic black level calibration (ABLC) ¬ standard serial SCCB interface with
speed up to 1 MHz
¬ programmable controls for:
- frame rate
- mirror and flip
- cropping
- windowing
(when clock input is >10 MHz)
¬ up to 4-lane MIPI TX interface with
speed up to 1.92 Gbps/lane
Product Specifications
¬ embedded 20 kbits of one-time
programmable (OTP) memory
¬
active array size: 5184 x 3888
¬
lens chief ray angle: 34.86° non-linear
¬ support for dynamic DPC cancellation
¬
power supply:
- core: 1.05V
- analog: 2.8V
- I/O: 1.8V
¬
maximum image transfer rate:
- 5184x3888: 30 fps
¬ supports output formats:
- 10-bit RAW RGB
- DPCM 10-8 compression
¬ sequential multi-frame HDR and
ZigZag HDR support
¬
¬
¬
¬
¬
¬
¬
¬
input clock frequency: 6 ~ 27 MHz
¬ phase detection auto focus (PDAF)
pixels with bypass PD pixels
-
¬ supports horizontal and
vertical subsampling
¬
¬
power requirements:
- active: 349 mW
- standby: 10 mW
- XSHUTDOWN: 5 µA
sensitivity: 3,400 e /Lux-sec
¬ gyro interface with 4-wire SPI
and EIS support
max S/N ratio: 37.3 dB
¬ supports typical images sizes:
- 5184 x 3888
dynamic range: 72.9 dB @ 16x gain
scan mode: progressive
- 3840 x 2160
¬ long exposure time of
up to 30 seconds
temperature range:
- operating: -30°C to +85°C junction
temperature
- stable image: 0°C to +60°C junction
temperature
- 2560 x 1440
- 1920 x 1080
- 1280 x 720
¬ two on-chip phase lock loops (PLLs)
¬ built-in temperature sensor
pixel size: 1.00 µm x 1.00 µm
image area: 5257.73 µm x 3951.36 µm
- 1000 x 568
- 800 x 480
¬
¬
output formats: 10-bit RGB RAW,
DPCM 10-8 compression
¬ programmable I/O drive capability
¬ typical module size: 8.5 x 8.5 x 5.3 mm
die dimensions:
- COB: 6210 µm x 4446 µm
- RW: 6260 µm x 4515.8 µm
lens size: 1/2.76"
Functional Block Diagram
OV20880
image sensor core
sensor
processor
interface
column
sample/hold
MCP/N
MDP/N[3:0]
10-bit
ADC
AMP
array
temperature
sensor
gain
control
control register bank
timing generator and
system control logic
SCCB
interface
gyro interface with
4-wire SPI master
PLLs
PLL
