WTD4A60S
Sensitive Gate Triac
Features
�
�
�
�
�
Repetitive Peak off -State Voltage:600V
R.M.S On-State Current(IT(RMS)=4A)
Low On-State Voltage (1.6V(Max.)@ITM
High Commutation dv/dt
Sensitive Gate Triggering 4 Mode
General Description
Sensitive gate triggering Triac is suitable for direct couplingto
TTL , CMOS and application such as various logic Functions, low
power AC switching applications,such as fanspeed,small light
controllers and home appliance equipment.
Absolute Maximum Ratings (TJ=25℃ unless otherwise specified)
symbol
VDRM
Parameter
condition
Ratings
600
Units
Repetitive Peak Off-State Voltage
V
IT(RMS)
R.M.S On-State Current
Tc=109℃
4.0
A
One Cycle, 50Hz/60Hz,
Peak,Non-Repetitive
ITSM
Surge On-State Current
30/33
A
I2t
PGM
PG(AV)
IGM
I2t
4.5
1.5
A2s
W
W
A
Peak Gate Power Dissipation
Average Gate Power dissipation
Peak Gate Current
0.1
1.0
VGM
TJ
Peak Gate Voltage
7.0
V
Operating Junction Temperature
Storage Temperature
-40~125
-40~150
℃
℃
TSTG
Thermal Characteristics
Symbol
Parameter
Value
2.6
Units
RӨJC
Thermal Resistance Junction to case(DC)
℃/W
RӨJA
Thermal resistance Junction to Ambient(DC)
100
℃/W
Rev.A Aug.2010
Copyright@WinSemi Semiconductor Co., Ltd., All right reserved.
