IXBF 40N160
= 28 A
VCES = 1600 V
VCE(sat) = 6.2 V
IC25
High Voltage
BIMOSFETTM
in High Voltage ISOPLUS i4-PACTM
tf
= 40 ns
Monolithic Bipolar MOS Transistor
1
5
Features
IGBT
• High Voltage BIMOSFETTM
- substitute for high voltage MOSFETs
with significantly lower voltage drop
- fast switching for high frequency
operation
Symbol
Conditions
Maximum Ratings
VCES
VGES
TVJ = 25°C to 150°C
1600
20
V
V
- reverse conduction capability
IC25
IC90
TC = 25°C
TC = 90°C
28
16
A
A
• ISOPLUS i4-PACTM
high voltage package
- isolated back surface
15/0
ICM
VCEK
VGE
=
V; R = 22 Ω; TVJ = 125°C
40
0.8VCES
A
RBSOA, ClampGed inductive load; L = 100 µH
- enlarged creepage towards heatsink
- enlarged creepage between high
voltage pins
Ptot
TC = 25°C
250
W
- application friendly pinout
- high reliability
- industry standard outline
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
Applications
min.
typ. max.
• switched mode power supplies
• DC-DC converters
• resonant converters
• lamp ballasts
• laser generators, x ray generators
VCE(sat)
IC = 20 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
6.2
6.9
7.1
V
V
VGE(th)
ICES
IC = 2 mA; VGE = VCE
4
8
V
VCE = 0.8VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.4 mA
mA
0.8
IGES
VCE = 0 V; VGE
=
20 V
500 nA
td(on)
tr
td(off)
tf
200
60
300
40
ns
ns
ns
ns
Inductive load, TVJ = 125°C
VCE = 960 V; IC = 25 A
15/0
V; RG = 22 Ω
VGE
=
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600V; VGE = 15 V; IC = 20 A
3300
130
pF
nC
VF
(reverse conduction); IF = 20A
2.5
V
RthJC
0.5 K/W
IXYS reserves the right to change limits, test conditions and dimensions.
© 2006 IXYS All rights reserved
1 - 4
