FZAM18N1150

型号:

FZAM18N1150

品牌:

IVO[ BAUMER IVO GMBH & CO. KG ]

页数:

1 页

PDF大小:

66 K

Photoelectric sensors
Diffuse sensors with
intensity difference
FZAM 18N1150
dimension drawing
M18x 1
SW 24
Pot 270˚
LED
general data
type
intensity difference
pulsed infrared diode
60 ... 430 mm
80 ... 800 mm
flashing light indicator
LED yellow
light source
sensing distanceTw
sensing distanceTw (with doubling lense)
alignment / soiled lens indicator
light indicator
sensitivity adjustment
potentiometer, 270°
880 nm
wave length
suppression of reciprocal influence
yes
electrical data
response time / release time
voltage supply range +Vs
current consumption max. (no load)
current consumption typ.
voltage drop Vd
< 1 ms
10 ... 30 VDC
45 mA
connection diagram
30 mA
< 1,8 VDC
light operate
NPN
BN (1)
+V
S
output function
Z
BK (4)
output circuit
output
0 V
NPN
output current
< 200 mA
yes
BU (3)
short circuit protection
reverse polarity protection
yes
mechanical data
width / diameter
height / length
type
18 mm
50 mm
cylindrical threaded
brass nickel plated / PC
PC
housing material
front (optics)
connection types
cable 3 pin, 2 m
ambient conditions
operating temperature
protection class
-25 ... +55 °C
IP 67
www.baumer.com
FZAM 18N1150
7/1/2014
