PX10FR02NH-1

型号：

PX10FR02NH-1

品牌：

JAE[ JAPAN AVIATION ELECTRONICS INDUSTRY, LTD. ]

页数：

8 页

PDF大小：

322 K

下载PDF手册
Introduction
apan Aviation Electronics Industry, Ltd. (JAE) is an international
manufacturer and supplier of electronic components and
J
systems. For over four decades, JAE has provided the electronics
industry with solutions to complex design requirements. Since its
founding, the Company has strived to contribute to society through
market-driven, technology-based global business operations under the
philosophy: “Technology to Inspire Innovation.”
With worldwide and world-class manufacturing certified to ISO
9001 and QS 9000, JAE has made the commitment to meet the global
requirements of our customer. In addition to a network of state of the
art manufacturing facilities, JAE has technical service offices located
around the world, staffed with experts in connector design
and application.
This catalog contains a select overview of JAE Connector Products.
For in-depth information on our complete product line, and
information on new developments, visit JAE’s online catalog at
www.jae-connector.com.
Innovative design, quality oriented manufacturing, commitment to our
customers and sensitivity to the environment assures JAE’s leadership
position in the 21st century.
Table of Contents
Product Series
Contact Spacing
Pages
So c k e t S /Me M o r y Pr o d u c t S
PCMCIA
JC22.......................................................1.27mm (.050") .............................................................5
COMPACT FLASH
JC26C2 ..................................................1.27mm (.050") ....................................................... 6 - 7
JC26E.....................................................1.27mm (.050") .............................................................8
JC26F.....................................................1.27mm (.050") .............................................................9
PCI EXPRESS MINI CARD
MM60....................................................0.8mm (.031") .............................................................10
EXPRESSCARD
PX10/11 .................................................1.0mm (.039") ..................................................... 11 - 12
PX20/22 .................................................1.0mm (.039") / 0.635mm (.025")........................ 13 -14
SMART/SIM CARD
SF2.........................................................2.54mm (.100") ...........................................................15
SF3.........................................................2.54mm (.100") ...........................................................16
SF6.........................................................2.54mm (.100") ...........................................................17
SF7.........................................................2.54mm (.100") ...........................................................18
SF7 (Slim)..............................................2.54mm (.100") ...........................................................19
SF9.........................................................2.54mm (.100") ...........................................................20
SECURE DIGITAL CARD
SG5 ........................................................2.50mm (.098") ...........................................................21
MINI SECURE DIGITAL CARD (SD)
ST4.........................................................1.1mm (.043") .............................................................22
SC1.........................................................2.50mm (.098") ...........................................................23
MICRO SD/TRANSFLASHTM
ST1.........................................................1.1mm (.043") .............................................................24
ST2.........................................................1.1mm (.043") .............................................................25
Bo a r d -t o -Bo a r d co n n e c t o r Pr o d u c t S
BOARD-TO-BOARD
AA03......................................................0.40mm (.020") ...........................................................26
WA6.......................................................0.40mm (.020") ...........................................................27
WH1.......................................................0.40mm (.020") ...........................................................28
AA01A ...................................................0.50mm (.020") ...........................................................29
IL-312.....................................................0.50mm (.020") ...........................................................30
WR.........................................................0.50mm (.020") ................................................... 31 - 32
WB3.......................................................0.50mm (.020 ") ..........................................................33
IL-WX ....................................................0.80mm (.031") ...........................................................34
KX14/15 .................................................0.80mm (.031") ................................................... 35 - 36
PM1 .......................................................0.80mm (.031") ...........................................................37
WM1......................................................1.00mm (.039) ............................................................38
WM2......................................................1.00mm (.039) ............................................................39
TX24/TX25.............................................1.27mm (.050") ...........................................................40
Table of Contents
Product Series
Contact Spacing
Pages
Bo a r d -t o -Bo a r d co n n e c t o r Pr o d u c t S
WIRE-TO-BOARD
PCB-TO-FPC/FFC
FB3.........................................................0.30mm (.012") ...........................................................41
FB5.........................................................0.30mm (.012") ...........................................................42
FB6.........................................................0.30mm (.012") ...........................................................43
FF02........................................................0.30mm (.012") ...........................................................44
FF02S.....................................................0.30mm (.012") ...........................................................45
FB8.........................................................0.30mm (.012") ...........................................................46
FA5.........................................................0.50mm (.020") ...........................................................47
FF03........................................................0.50mm (.020") ...........................................................48
IL-FPR....................................................0.50mm (.020") ...........................................................49
PCB-TO-CABLE/FPC
FI-J.........................................................0.40mm (.016") ................................................... 50 - 51
FI-R ........................................................0.50mm (.020") ................................................... 52 - 53
FI-X ........................................................1.00mm (.039") ................................................... 54 - 55
FI ............................................................1.25mm (.049") ................................................... 56 - 58
PCB-TO-CABLE
DX2/3.....................................................0.80mm (.031") ...........................................................59
FI-E.........................................................1.00mm (.039") ................................................... 60 - 61
CN10................................................................................................................................... 62 - 63
CV10............................................................................................................................................64
IL-Z.........................................................1.25mm (.049") ................................................... 65 - 66
IL-S ........................................................2.00mm (.079") ................................................... 67 - 68
LY............................................................2.00mm (.079") ...........................................................69
KD10/20.................................................2.00mm (.079") ...........................................................70
IL-G........................................................2.50mm (.098") ...........................................................71
In P u t /ou t P u t co n n e c t o r Pr o d u c t S
PCB-TO-CABLE
DD1........................................................0.50mm (.020") ................................................... 72 - 73
DD2........................................................0.50mm (.020") ................................................... 74 - 75
DG1........................................................0.50mm (.020") ...........................................................76
RA1 ........................................................0.50mm (.020") ...........................................................77
RC1.........................................................0.50mm (.020") ...........................................................78
DA1........................................................0.60mm (.024") ...........................................................79
DE1.........................................................1.27mm (.050") ...........................................................80
TX20A....................................................1.27mm (.050") ...........................................................81
DV2 ........................................................1.905mm (.075") ................................................. 82 - 84
CIRCULAR
JN1 ..................................................................................................................................... 85 - 86
JN2 ..................................................................................................................................... 87 - 88
JB5..............................................................................................................................................89
Table of Contents
Product Series
Contact Spacing
Pages
In P u t /ou t P u t co n n e c t o r Pr o d u c t S
CIRCULAR
JL04V.................................................................................................................................. 90 - 91
JL05 .................................................................................................................................... 92 - 93
JB1...................................................................................................................................... 94 - 95
SRCN.................................................................................................................................. 96 - 97
N/MS.................................................................................................................................. 98 - 99
FI B e r oP t I c Pr o d u c t S
FO-FC........................................................................................................................................100
FO-EX........................................................................................................................................101
au t o M o t I v e co n n e c t o r Pr o d u c t S
PCB-TO-CABLE
MX34 ...................................................1.1mm (.043") .............................................................102
MX7 .....................................................2.30mm (.091") ...........................................................103
IL-AG7 .................................................2.50mm (.098") ...........................................................104
MX17 ...................................................2.50mm (.098") ................................................. 105 - 106
MX23A.................................................2.50mm (.098") ................................................. 107 - 108
MX10 ...................................................2.50mm (.098") ...........................................................109
MX5 .....................................................3.00mm (.118") ...........................................................110
PCB-TO-CABLE/CABLE-TO-CABLE
IL-AG5 .................................................2.50mm (.098") ...........................................................111
IL-AG6 .................................................2.50mm (.098") ...........................................................112
MX9 .....................................................3.50mm (.138") ...........................................................113
MX25 ...................................................6.7mm (2.64") .............................................................114
MX36 ...................................................2.50mm (.098") ...........................................................115
CABLE-TO-CABLE
IL-AG9 .................................................2.50mm (.098") ................................................. 116 - 118
MX19 ...................................................2.50mm (.098") ...........................................................119
•
•
All JAE connector products shown in this catalog are lead free.
We reserve the right to modify designs in order to improve quality, keep pace with technological advancements or meet
particular requirements in production.
•
Products shown in this catalog are made for the applications specified. However, if the above-mentioned products are to be
used in aerospace devices, marine cable-connection devices, atomic power control systems, medical equipment for life-
support systems, or any other specific application requiring extremely high reliability, please contact JAE for further
information. Recommended Applications: Computers, Office Machines, Measuring Devices, Telecommunications Devices
(Terminals, Mobile Devices) AV Devices, Household Applications, FA Devices, etc.
•
Refer to end of catalog for alphabetical index of products.
PX10/11 SERIES CONNECTORS
1.0mm (.039") Contact Spacing, Host Connector for PCMCIA Express Card
• • • • • • • • • • • • • •
The PX10/11 Series connectors are host connectors for the PCI
ExpressCard®. The PX10 connectors are for use with 34mm/54mm
(1.34"/2.12") cards and PX11 connectors are PX10 and PX11 Series
connectors are designed for 34mm (1.34" cards, but will also accept
the 54mm (2.12") cards. The connectors conform to the PCMCIA
standard for both the PCI ExpressCard (x1) and USB2.0 (x2) interfaces.
GENERAL SPECIFICATIONS
Number of Contacts
Contact Spacing
26 pos
1.0mm (.039")
Contact Resistance
40m milliohms max. (after test 55m
ohm max.)
Withstanding Voltage
Operating Temperature
Rated Current
AC 500Vrms per min.
0°C to +55°C (degree of humidity 95%)
0.75A/per pin
FEATURES
• Conforms to PCI ExpressCard standard (Rev. 10)
• Two-body structure consists of PCB and cage,
compatible to automated mounting and reflow
• Structure is drop impact resistant
• Features Push-Push card eject structure
• Available in standard, reverse and stand-off
mounting types
Lifetime
5,000 times
Insertion Loss:
-1.7dB max. (3.125Ghz max.)
-5.5dB max. (6Ghz max.)
Return Loss
-10dB max. (3.125Ghz max.)
-5dB max. (6Ghz max.)
• Complies with PCMCIA standard
Cross Talk (NEXT)
-32dB Max. (3.125Ghz max.)
-26dB max. (6Ghz max.)
Connector Profile (Ref.)
MATERIALS AND FINISHES
38.7
7.3
(1.52)
(.287)
• PCB Side
Description
Contact
Materials/Finishes
Copper Alloy/0.1µm min. Gold plating over Nickel
PPS (UL94V-0)
Insulator
• Cage
Frame/Cam
Follower/Slider/
Lower Plate
SUS
Hart Cam/
PBT (UL94V-0)
Stopper/Guide
Spring
SWPB
Nut/Boss
Aluminium
34.8
(1.37)
42
(1.65)
Dimensions in mm (inches).
11
PX10/11 SERIES CONNECTORS
1.0mm (.039") Contact Spacing, Host Connector for PCMCIA Express Card
ORDERING INFORMATION - PCB
PX10
ORDERING INFORMATION - Cage
PX10
F
S
02
P H - 1
B
S
B
02 -
1
Series
PCB
Series
Cage
Mounting Type
S - Standard
R - Reverse
Positioning Boss
B - with
N - without
Height Code ****
Modification Code
Mounting Type
S - Standard
R - Reverse
Height Code ****
Bottom Plate
P - with
N - without
Nut
H - with
N - without
Modification Code
**** Please use PCB side and cage with same
height code.
PX10 Series (for 34/54 Module)
Specification
Part Number
Mounting type
Standard
Standoff height
Lower stand
Cage
PCB side
PX10BSB00
PX10BSB02
PX10BSB16
No
Yes
Yes
PX10FS00NH
PX10FS02PH
PX10FS16PH
0.0
1.5 0.2
PX11 Series (for 34 Module)
Specification
Standoff height
0.0
Part Number
Mounting type
Standard
Lower stand
Cage
PX11FS00NH
PX11FS16PH
PCB side
PX10BSB00
PX10BSB16
No
No
1.85 0.2
PX10 Series
Part Number Standoff Height
PX11 Series
Part Number Standoff Height
Height Code
PCB Side
00
02
16
PX10B*B00
PX10B*B02
PX10B*B16
PX10F*00NH
PX10F*02PH
PX10F*16PH
PX11F*00NH
0.0
0.0
1.5 0.2
PX11F*16NH
1.85 0.2
Dimensions and specifications subject to change without notice.
12
Japan Aviation Electronics Industry, Limited
1-19, Aobadai 3-chome, Meguro-ku
Tokyo 153-8539, Japan
Telephone: 03-3780-2736
Fax: 03-3780-2883
JAE Electronics, Inc.
“Building Technologies
to Connect Your World”
142 Technology Drive, Suite 100
Irvine, California 92618-2430, U.S.A.
Telephone: 949-753-2600
Fax: 949-753-2699
800-523-7278 Toll free in the U.S.A.
JAE Europe
Coliseum Business Centre
Riverside Way, Camberley
Surrey, GU15 3YL, England
Telephone: 44-1276-404000
Fax: 44-1276-404010
JAE Taiwan, Ltd.
4F-1, No. 88, Chung Hsiao E. Rd.
Sec. 2, Taipei, Taiwan, R.O.C.
Telephone: 886-2-2396-7676
Fax: 886-2-2392-5929
JAE Hong Kong, Ltd.
Suites 1407-11, 14/F, Tower 2, The Gateway,
25 Canton Road, Tsimshatsui, Kowloon, Hong Kong
Telephone: 852-2723-7782
Fax: 852-2723-9028
JAE Korea, Inc.
1602, Korea City Air Tower
159-9 Samsung-Dong, Kangnam-ku
Seoul, 135-973, Korea
Telephone: 82-2-551-8959
Fax: 82-2-551-8958
JAE Philippines, Inc.
PEZA Zone, Gateway Business Park, Javalera
General Trias, 4107 Cavite, Philippines
Telephone: 63-46-433-0285
Fax: 63-46-433-0287
JAE Singapore Pte., Ltd.
33 Tannery Lane, #02-01 Hoesteel
Industrial Building
Singapore 347789
Telephone: 65-6748-1332
Fax: 65-6748-2920
JAE Shanghai Co., Ltd.
RM 1407, Shanghai Mart 2299 Yanan Rd.
West Shanghai 200336 P.R.C.
Telephone: 86-21-6236-0322
Fax: 86-21-6236-1292
Printed in the U.S.A. 10M807TA SF3
厂商 型号 描述 页数 下载

HRS

 		PX10-AD4WP 电源连接器工业设备[ Power Supply Connectors For Industrial Equipment ] 8 页

HRS

 		PX10-AD4WP50 电源连接器工业设备[ Power Supply Connectors For Industrial Equipment ] 8 页

HRS

 		PX10-AF6WP 电源连接器工业设备[ Power Supply Connectors For Industrial Equipment ] 8 页

HRS

 		PX10-AF6WP(50) [ Rectangular Power Connector, 8 Contact(s), Female, Solder Terminal, Receptacle, ROHS COMPLIANT ] 8 页

HRS

 		PX10-AF6WP50 电源连接器工业设备[ Power Supply Connectors For Industrial Equipment ] 8 页

HRS

 		PX10-AF6WP_06 电源连接器工业设备[ Power Supply Connectors For Industrial Equipment ] 8 页

MURATA

 		PX10004 [ SAW Filter, 1 Function(s), 82.2MHz ] 5 页

RFM

 		PX1002 专为TDMA IS- 54接收器IF应用[ Designed for TDMA IS-54 Receiver IF Applications ] 10 页

ETC

 		PX10020EJ06V0PF 射频和微波器件选型指南 - 应用系统 - \n[ RF and Microwave Devices Selection Guide -Application System- ] 38 页

RFM

 		PX1004 82.2 MHz的SAW滤波器[ 82.2 MHz SAW Filter ] 10 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.189749s
