RFM products are now
Murata products.
PX10004
• Designed for TDMA IS-54 / CDPD IF Applications
• Low Insertion Loss
• Excellent Selectivity
• Hermetic 13.3 X 6.5 mm Surface-Mount Case
• Unbalanced Input and Output
82.2 MHz
SAW Filter
• Complies with Directive 2002/95/EC (RoHS)
Pb
Absolute Maximum Ratings
Rating
Value
+10
Units
dBm
VDC
°C
Maximum Incident Power in Passband
Max. DC voltage between any 2 terminals
Storage Temperature Range
30
-40 to +85
Suitable for lead-free soldering - Max Soldering Profile
260°C for 30 s
SM13365-12
Electrical Characteristics
Characteristic
Sym
Notes
Min
Typ
Max
Units
fC
82.200
Nominal Center Frequency
MHz
1
Passband
Insertion Loss at fc
3 dB Passband
3
4.0
dB
IL
BW3
±15
±25
kHz
dBP-P
µsP-P
dBm
Amplitude Ripple over fc ±15 kHz
1.0
6.0
-95
1, 2
Group Delay Variation over fc ±10 kHz
GDV
2.5
Third-Order Intermod. for -20 dBm tones at fc ±60 & 120 kHz
Rejection
fc ±60 kHz
10
65
16
68
65
fc -880 kHz to fc -940 kHz
Ultimate
1, 2, 3
1
dB
°C
TA
Operating Temperature Range
+70
-20
Impedance Matching to 50 Ω unbalanced
External L-C
Case Style
SM13365-12 13.3 X 6.5 mm Nominal Footprint
RFM PX1004 YYWW
Lid Symbolization (YY=year, WW=week) See note 4
Electrical Connections
Connection
Terminals
Port 1Hot
2
Port 1 Gnd Return
Port 2 Hot
3
8
9
Port 2 Gnd Return
Case Ground
All Others
Caution: Electrostatic Sensitive Device. Observe precautions for handling.
NOTES:
1.
Unless noted otherwise, all specifications apply over the operating temperature
range with filter soldered to the specified demonstration board with impedance
matching to 50 Ω and measured with 50 Ω network analyzer.
5.
The design, manufacturing process, and specifications of this filter are subject
to change.
Either Port 1 or Port 2 may be used for either input or output in the design.
However, impedances and impedance matching may vary between Port 1 and
Port 2, so that the filter must always be installed in one direction per the circuit
design.
US and international patents may apply.
Murata, stylized Murata logo, and Murata N.A., Inc. are registered
trademarks of Murata Manufacturing Co., Ltd.
6.
2.
3.
Unless noted otherwise, all frequency specifications are referenced to the
nominal center frequency, fc.
Rejection is measured as attenuation below the minimum IL point in the
passband. Rejection in final user application is dependent on PCB layout and
external impedance matching design. See Application Note No. 42 for details.
"LRIP" or "L" after the part number indicates "low rate initial production" and
"ENG" or "E" indicates "engineering prototypes."
7.
8.
4.
©2010-2015 by Murata Electronics N.A., Inc.
PX10004 (R) 2/12/15
