Oscillator · VX3 · 3.3 V
SMD Oscillator with Tristate Function · 7.0 x 5.0 mm
RoHS
■
■
■
preferred type for extended temperature range
reflow soldering temperature: 260 °C max.
full ceramic package
2002/95/EC
actual size
RoHS compliant
Pb free: pins / pads
General Data
Table 1: Type
stability
100 ppm
50 ppm
MH
15 pꢀ 30 pꢀ 15 pꢀ 30 pꢀ 15 pꢀ 30 pꢀ 15 pꢀ 30 pꢀ 15 pꢀ 30 pꢀ
30 ppm
25 ppm
20 ppm
type
VX3 3.3 V
type VX3
J
M
K
JS
MS
JQ
MQ
JP
MP
frequency range
0.50 ~ 70.0 MHz (15pꢀ max.)
0.50 ~ 70.0 MHz (30pꢀ max.)
20ppm ~ 100ppm (table 1)
see table 2
output load
-10 °C ~ +70 °C
-40 °C ~ +85 °C
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Δ
Δ
frequency stability over all*
current consumption
supply voltage VDC
temperature operating
storage
•
•
standard
O available
Δ excludes aging
3.3 V 10ꢁ
•
* includes stability at 25 °C, operating temp. range, supply voltage change, shock and vibration, aging 1st year.
-10 °C ~ +70 °C / -40 °C ~ +85 °C
-55 °C ~ +125 °C
Table 2: Current Consumption max.
output
rise & fall time see table 3
Current at 15pF load
Current at 30pF load
load max
15pꢀ / 30pꢀ
8mA
0.5 ~ 33.9 MHz
34.0 ~ 49.9 MHz
50.0 ~ 70.0 MHz
8 mA
12 mA
25 mA
0.5 ~ 33.9 MHz
34.0 ~ 49.9 MHz
50.0 ~ 70.0 MHz
10 mA
20 mA
25 mA
current max.
low level max. 0.1 x VDC
high level min. 0.9 x VDC
output enable time max.
output disable time max.
start-up time max.
100ns
100ns
10ms
Table 3: Rise & Fall Time max.
note:
8.0 ns: 0.5 ~ 1.79 MHz
6.0 ns: 1.8 ~ 34.99 MHz
5.0 ns: 35.0 ~ 70.00 MHz
standby function
tristate
- specific data on request
- rise time: 0.1 VDC ~ 0.9 VDC
- fall time: 0.9 VDC ~ 0.1 VDC
phase jitter 12 kHz ~ 20.0 MHz < 1.0ps RMS
symmetry at 0.5 x VDC
45ꢁ ~ 55ꢁ typ. (40ꢁ ~ 60ꢁ max.)
Dimensions
0.1
1.8
0.2
0.1
7.0
1.4
# 4 # 3
# 3
# 4
pin connection
# 1: e/d
# 2: ground
# 3: output
# 4: VDC
# 1 # 2
top view
# 2
# 1
0.1
5.08
0.1
5.08
in mm
side view
bottom view
pad layout
Order Information
Preferred Type
VX3MH-T1:
VX3MH:
50 ppm / 30 pꢀ/ -40 °C ~ +85 °C
50 ppm / 30 pꢀ
frequency
type
option
O
Oscillator
0.5 ~ 70.0 MHz
VX3J-VX3MP
see table 1
blank = -10 °C ~ +70 °C
T1 = -40 °C ~ +85 °C
Example: O 20.0-VX3MH (LF = RoHS compliant / Pb free pads)
•
Jauch Quartz GmbH e-mail: info@jauch.de
full data can be found under: www.jauch.de / www.jauch.fr / www.jauchusa.com
All specifications are subject to change without notice
