Part Number:
SURFACE MOUNT DISPLAY
XZDMDK10A
www.SunLED.com
ꢀ Recommended Soldering Pattern (Units : mm;Tolerance:± 0.15)
ꢀ Tape Specification (Units : mm)
Remarks:
If special sorting is required (e.g. binning based on forward voltage, luminous intensity, or wavelength), the typical
accuracy of the sorting process is as follows:
1. Wavelength: +/-1nm
2. Luminous Intensity: +/-15%
3. Forward Voltage: +/-0.1V
Note: Accuracy may depend on the sorting parameters.
Published Date : MAY 19, 2005
Drawing No : XDSA3008
V6
Checked : Shin Chi
P.3/3
