2STF1550_08

型号：

2STF1550_08

描述：

低电压高性能NPN功率晶体管[ Low voltage high performance NPN power transistors ]

品牌：

STMICROELECTRONICS[ ST ]

页数：

8 页

PDF大小：

143 K

下载PDF手册
2STF1550
2STN1550
Low voltage high performance NPN power transistors
Preliminary Data
Features
■ Very low collector-emitter saturation voltage
■ High current gain characteristic
■ Fast switching speed
4
4
■ Surface mounting devices in medium power
3
3
2
SOT-89 and SOT-223 packages
2
1
1
Applications
SOT-223
SOT-89
■ Emergency lighting
■ LED
■ Motherboard and hard disk drive
■ Mobile equipment
■ Battery charger
Figure 1.
Internal schematic diagram
■ Voltage regulation
Description
The 2STF1550 and 2STN1550 are NPN
transistors manufactured using new “PB-HCD”
(Power bipolar high current density) technology.
The resulting transistor shows exceptional high
gain performances coupled with very low
saturation voltage.
Table 1.
Device summary
Order codes
Marking
Package
SOT-89
SOT-223
Packaging
2STF1550
2STN1550
1550
Tape and reel
N1550
November 2008
Rev 2
1/8
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to
change without notice.
www.st.com
8
Electrical ratings
2STF1550 - 2STN1550
1
Electrical ratings
Table 2.
Symbol
Absolute maximum rating
Parameter
Value
2STF1550
SOT-89
2STN1550
SOT-223
Unit
VCES
VCEO
VEBO
IC
Collector-emitter voltage (VCE = 0)
Collector-emitter voltage (IB = 0)
Emitter-base voltage (IC = 0)
Collector current
50
50
5
V
V
V
5
A
ICM
Collector peak current (tP < 5 ms)
Base current
10
1
A
IB
A
PTOT
Tstg
TJ
Total dissipation at Tamb = 25 °C
Storage temperature
1.4
1.6
W
°C
°C
-65 to 150
150
Max. operating junction temperature
Table 3.
Symbol
Thermal data
Parameter
SOT-89
89
SOT-223
Unit
(1)
Thermal resistance junction-amb
__max
78
°C/W
Rthj-amb
1. Device mounted on PCB area of 1 cm2
2/8
2STF1550 - 2STN1550
Electrical characteristics
2
Electrical characteristics
(T
= 25 °C unless otherwise specified)
case
Table 4.
Symbol
Electrical characteristics
Parameter
Test conditions
VCB = 50 V
Min. Typ. Max. Unit
Collector cut-off current
ICBO
0.1
0.1
μA
μA
(IE = 0)
Emitter cut-off current
(IC = 0)
IEBO
VEB = 4 V
Collector-base
breakdown voltage
V(BR)CBO
IC = 100 μA
50
V
(IE = 0)
Collector-emitter
breakdown voltage
(1)
V(BR)CEO
IC = 10 mA
50
5
V
V
(IB = 0)
Emitter-base breakdown
voltage (IC = 0)
V(BR)EBO
IE = 100 μA
IC = 0.5 A
IC = 2 A
IC = 3 A
IC = 5 A
VCE = 2 V
VCE = 2 V
VCE = 2 V
VCE = 5 V
250
135
100
400
(1)
hFE
DC current gain
95
Collector-emitter
saturation voltage
(1)
VCE(sat)
VBE(sat)
CCBO
IC = 3 A
IC = 3 A
IB = 300 mA
IB = 300 mA
0.26
0.45
1.2
V
V
Base-emitter saturation
voltage
(1)
1
Collector-base
capacitance (IE = 0)
VCB = 10 V, f = 1 MHz
20
pF
Resistive load
Turn-on time
Turn-off time
IC = 1.5 A
VCC = 10 V
ton
toff
90
ns
ns
IB1 = -IB2 = 150 mA
700
1. Pulsed duration = 300 μs, duty cycle ≤1.5%
3/8
Package mechanical data
2STF1550 - 2STN1550
3
Package mechanical data
In order to meet environmental requirements, ST offers these devices in ECOPACK®
packages. These packages have a lead-free second level interconnect. The category of
second level interconnect is marked on the package and on the inner box label, in
compliance with JEDEC Standard JESD97. The maximum ratings related to soldering
conditions are also marked on the inner box label. ECOPACK is an ST trademark.
ECOPACK specifications are available at: www.st.com
4/8
2STF1550 - 2STN1550
Package mechanical data
SOT-89 MECHANICAL DATA
mm
mils
DIM.
MIN.
1.4
TYP.
MAX.
1.6
MIN.
55.1
17.3
14.2
13.8
13.8
173.2
63.8
90.2
55.9
115.0
155.1
35.0
TYP.
MAX.
63.0
A
B
0.44
0.36
0.35
0.35
4.4
0.56
0.48
0.44
0.44
4.6
22.0
B1
C
18.9
17.3
C1
D
17.3
181.1
72.0
D1
E
1.62
2.29
1.42
2.92
3.94
0.89
1.83
2.6
102.4
61.8
e
1.57
3.07
4.25
1.2
e1
H
120.9
167.3
47.2
L
P025H
5/8
Package mechanical data
2STF1550 - 2STN1550
SOT-223 mechanical data
mm.
typ
DIM.
min.
max.
1.80
0.1
A
A1
B
0.02
0.60
2.90
0.24
6.30
0.70
3.00
0.26
6.50
2.30
4.60
3.50
7.00
0.85
3.15
0.35
6.70
B1
c
D
e
e1
E
3.30
3.70
7.30
H
6.70
o
V
10
0046067_L
6/8
2STF1550 - 2STN1550
Revision history
4
Revision history
Table 5.
Date
Document revision history
Revision
Changes
08-May-2007
12-Nov-2008
1
2
Initial release
Updated SOT-223 mechanical data
7/8
2STF1550 - 2STN1550
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZE REPRESENTATIVE OF ST, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS, WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS “AUTOMOTIVE
GRADE” MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2008 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
8/8
