12V 7.2Ah
XTV1272
XTV 1272 is a general battery up to 12 years expected
life in standby service or more than 260 cycles at
100% discharge in cycle service . XTV!has a wider
operating temperature range, which makes them more
suitable for the systems in harsh conditions.
Specification
Cells Per Unit
6
Voltage Per Unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
12
7.2Ah @ 10hr-rate to 1.80V per cell @25 (77
Approx. 2.75 kg(6.06 lbs)
130A(5sec)
Approx. 21m
Discharge: -20 ~50 (-4 ~122
)
)
Charge: -20 ~50
Storage: -20 ~50
(-4 ~122
(-4 ~122
)
)
Nominal Operating Temperature Range 25
3
(77
5 )
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
13.5 to 13.8 VDC/unit Average at 25 (77
2.16A
)
)
14.4 to 15.0 VDC/unit Average at 25 (77
CSB-manufactured
CSB Batteries can be stored for more than 6 months at
25 (77 ). Please charge batteries before using . For
higher temperatures the time interval will be shorter.
F2-Faston Tab 250
VRLA batteries are UL-
recognized components
under UL924 and UL1989.
Terminal
CSB is also certified by
ISO 9001 and ISO 14001.
Container Material
ABS(UL 94-HB/File E50263)*Flammability resistance of
(UL 94-V0/File E88637) can be available upon request.
Dimensions :
Unit: mm (inch)
Overall Height (H)
100 1 (3.81 0.04)
Container height (h)
97 1 (3.7 0.04)
Length (L)
151 2.0 (5.94 0.08)
Width (W)
65 1.0 (2.56 0.04)
Tfbmfe Mfbe Cbuufsz/ Cbuufsz nvtu cf
sfdzdmfe/ Gps sfdzdmjoh jogpsnbujpo
Jotjef uif VTB dbmm )911* Sf.Vtf.Qc )849.8483*
Pvutjef uif VTB dbmm 2 )928* 355.5526
)iuuq;00xxx/dtc.cbuufsz/dpn*
cz UVW DFSU bddpsejoh up JTP :112-JTP 25112/
Constant Current Discharge Characteristics Unit:A (25 ,77
)
F.V/Time
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
5MIN
27.7
26.8
25.8
24.6
21.8
18.3
10MIN 15MIN 30MIN
1HR
4.61
4.48
4.41
4.31
4.23
4.11
2HR
2.68
2.63
2.62
2.60
2.57
2.48
3HR
1.93
1.90
1.89
1.88
1.86
1.80
4HR
1.53
1.50
1.49
1.48
1.47
1.42
5HR
1.26
1.25
1.24
1.23
1.22
1.19
8HR
0.888
0.877
0.868
0.847
0.828
0.802
10HR
0.712
0.708
0.703
0.698
0.689
0.670
20HR
0.389
0.385
0.380
0.375
0.371
0.366
17.7
17.4
17.1
16.4
15.4
13.9
13.4
13.3
13.2
12.9
12.3
11.2
7.94
7.87
7.82
7.75
7.53
7.10
Constant Power Discharge Characteristics Unit:W (25 ,77
)
F.V/Time
1.60V
1.67V
1.70V
1.75V
1.80V
1.85V
5MIN
299
290
282
264
239
206
10MIN 15MIN 30MIN
1HR
54.8
54.7
54.5
53.8
53.2
51.8
2HR
32.1
31.9
31.8
31.7
31.4
30.2
3HR
23.1
23.0
22.9
22.8
22.7
21.9
4HR
18.3
18.2
18.1
18.0
17.8
17.5
5HR
15.2
15.1
15.0
14.9
14.8
14.7
8HR
10.3
10.2
10.1
10.0
9.93
9.85
10HR
8.65
8.63
8.60
8.55
8.50
8.27
20HR
4.68
4.63
4.60
4.56
4.51
4.45
193
190
188
182
173
160
149
148
147
145
138
128
89.8
89.3
88.8
88.1
86.3
82.3
Ratings are preliminary and subject to change.
