IN74LV623
Absolute maximum ratings*
Symbol
Parameter
Value
Unit
VCC
Supply voltage
from -0.5 to
V
+5.0
IIK *1
Input diode current
Output diode current
Output current source-drain
Supply output current
mA
mA
mA
mA
mA
mW
±20
±50
±35
±70
±70
2
IOK
*
IO *3
ICC
IGND
PD
Common output current
Dissipation power at free air change,
4
Plastic
DIP
*
750
500
SOIC *4
Tstg
TL
Storage temperature
from -65 to
°C
°C
+150
260
*
Under absolute maximum conditions operation of microcircuits is not guaranteed.
Operation under maximum conditions is guaranteed.
*1 If VI < -0.5V or VI > VCC + 0.5 V.
*2 If VO < -0.5V or VO > VCC + 0.5 V.
*3 If -0.5V < VO < VCC + 0.5 V.
*4 Under operation in the temperature range from 65°С to 125°C value of dissipation
power drops down - to 10 mW/°C for Plastic DIP
- to 7 mW/°C for SOIC
Maximum conditions
Symbol
Parameter
Min
Max
Unit
VCC
VIN
Supply voltage
Input voltage
Output voltage
1.2
0
3.6
VCC
VCC
125
1000
700
500
400
V
V
VOUT
TA
0
V
Operation temperature. For all packages
-40
0
°C
ns
VCC =1.2 В
VCC =2.0 В
VCC =3.0 В
tLH, tHL
Period of signal rise and
fall edges (Figure 1)
VCC =3.6 В
2
