IZ7008

型号:

IZ7008

描述:

8位微控制器与LCD驱动器[ 8-BIT MICROCONTROLLER WITH LCD DRIVER ]

品牌:

INTEGRAL[ INTEGRAL CORP. ]

页数:

16 页

PDF大小:

445 K

IZ7008
8-BIT MICROCONTROLLER WITH LCD DRIVER
IZ7008 is one-chip 8-bit microcontroller made by CMOS technology. The microcon-
troller is multi-purpose and can be used in electronic watch, data acquisition systems, con-
trol systems. Low consumption power and full static CMOS logic allow to use MC in inde-
pendent systems with limited energy consumption.
Technical characteristics of IZ7008:
ALU bit capacity
RAM size
– 8 bits
– 40 bytes
ROM size
– 1,5 К of commands (16–bit instructions)
– 30 types of commands
– 7 levels
RISC commands system
Stack depth
Interrupter
– from 8- inputs and three timers
Maximum number of the controlled
LCD segments
– 128 (32 LCD control drivers
at multiplex levels
1/2,1/3,1/4)
Operation temperature range -20°С to +70 °С.
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
1
IZ7008
Electrical parameters at 1.5V supply
Absolute maximum and maximum ratings
Parameter, unit
Symbol
Maximum ratings
Absolute maximum ratings
Value
Value
min
1,2
max
1,8
min
-0,3
max
2,0
Primary supply voltage from
voltage source, V
UCC1
Secondary supply voltage, V
High input voltage, V
UCC2
UIH
UIL
2UCC1-0,3
UCC1-0,3
Uss
2UCC1
UCC1
Uss+0,3
-0,3
-0,3
-0,3
4,0
UCC1+0,3
UCC1+0,3
Low input voltage, V
Cycle of command execution is not more than 150 mks at supply voltage 1.2V, and
100 mks at supply voltage 1.5V.
IC operation is not guaranteed under absolute maximum conditions, it's guaranteed under
maximum conditions.
Electrical parameters ( Та = 25°С )
Parameter, unit
Symbol
UOL
Test
Value
Note
1,2
conditions
min
max
Low output voltage on alarm-
clock output, V
High output voltage on alarm-
clock output, V
U
СС1=1.2V
0.2
IOL=200mkA
СС1=1.2V
UOH
U
1.0
IOH=-200mkA
Dynamic consumption current in
shutdown conditions, mkA
Low input current on buttons
inputs, mkA
IСС0
U
СС1=1,5V
-
-
-
-
1,3
10
IIL
U
СС1=1,8V
UIL=0,3V
Oscillator start-up voltage, V
Uosc
Uosp
Control time 3
1,35
1,2
2
2
sec
-
Oscillator supression voltage, V
Notes:
1 Dynamic consumption current should be measured without load.
2 The parameters are controlled with oscillator crystal with oscillator nominal frequency 32768 Hz
at capacitance values on oscillator input OSCI not more than 6pF, on output OSCO - not more
than 3pF.
3 Nominal value of integrated capacitances on outputs OSCI and OSCO - 12pF and 12pF(crystal
load capacity CL=6 pF).
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
2
IZ7008
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
3
IZ7008
MICROCONTROLLER STRUCTURE
ROM
Internal ROM contains 1536 commands (16–bit instructions) at the addresses from 0x000
to 0x5FF. ROM area in the range from 0x000 to 0x0FF (256 commands) and from 0x3FE to
0x4A8 (178 commands) is reserved for interruptions processing programs, system reset and mi-
crocontroller testing. User's program if mainly located at the addresses from 0x100 to 0x3FD and
from 0x4AA to 0x5FF (1110 commands).
MICROCONTROLLER REGISTER RAM
RAM is organized as banks by 8 registers and contains internal function registers, data
RAM, special registers and data memory, directly displayed on LCD.
Microcontroller internal function registers are in the address area from 0x000 to 0x007
(bank 00). Their purpose:
R0, R1, R2, R3 - accumulators;
R4, R5, R6 - base address registers BL, BM, BH of storing number of addressed bank;
R7- register of microcontroller state (RGS).
Internal data RAM (RAM) of 40 bytes is in the address space from 0x008 to 0x02F (banks
01, 02, 03, 04, 05).
RAM registers addressing.
RO-R3, R4 (or BL), R5 (or BM), R6 (or BH), R8-R1F - names of RAM registers in the
commands at direct addressing. For registers RO-R7 only direct addressing is possible. For regis-
ters R8-RF (or L0-L7), R10-R17 (or M0-M7), R18-R1F (or H0-H7) direct addressing is possible
only if bit 0 in state register RGS (R7) is reset into 0, i.e. (R7_0)=0.
BL, BM, BH – base address registers (R4, R5, R6 respectively). At index register address-
ing the contents of base registers defines data bank number. At index addressing of RAM registers
the contents of base registers defines data bank number.
L0-L7, M0-M7, H0-H7 – names of RAM registers in commands at index addressing. For
names of registers LO-L7 data bank number is defined by contents of base register BL, for names
of registers MO-M7 data bank number is defined by contents of base register BM, for names of
registers HO-H7 data bank number is defined by contents of base register BH. To calculate physi-
cal address, the contents of base register indicated in the command should be multiplied by 8 and
a number from 0 to 7 should be added respectively. For example: when recording in the command
«M5» the physical address is equal to ((BM)*8+5).
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
4
IZ7008
Allocation of RAM and internal function registers addresses
Bank
00
N of reg-
Symbol at
Symbol at index
addressing
Description
ister in
Address
direct
the bank
addressing
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
0x000
0x001
0x002
0x003
0x004
0x005
0x006
0x007
0x008
0x009
0x00A
0x00B
0x00C
0x00D
0x00E
0x00F
0x010
R0
-
Accumulator
Accumulator
R1
-
R2
-
Accumulator
R3
-
Accumulator
R4 or BL
-
Base register BL
Base register BM
Base register BH
State register
R5 or BM
-
R6 or BH
-
R7
-
R8 или L0
L0,M0,H0
L1,M1,H1
L2,M2,H2
L3,M3,H3
L4,M4,H4
L5,M5,H5
L6,M6,H6
L7,M7,H7
L0,M0,H0
R9 или L1
RA или L2
01
RB или L3
Data RAM
RC или L4
RD или L5
RE или L6
RF или L7
R10 илиM0
M7
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0x011
0x012
0x013
0x014
0x015
0x016
0x017
0x018
0x019
0x01A
0x01B
0x01C
0x01D
0x01E
0x01F
0x020
0x021
0x022
0x023
0x024
0x025
0x026
0x027
0x028
0x029
0x02A
0x02B
0x02C
0x02D
0x02E
0x02F
R11 илиM1
L1,M1,H1
L2,M2,H2
L3,M3,H3
L4,M4,H4
L5,M5,H5
L6,M6,H6
L7,M7,H7
L0,M0,H0
L1,M1,H1
L2,M2,H2
L3,M3,H3
L4,M4,H4
L5,M5,H5
L6,M6,H6
L7,M7,H7
L0,M0,H0
L1,M1,H1
L2,M2,H2
L3,M3,H3
L4,M4,H4
L5,M5,H5
L6,M6,H6
L7,M7,H7
L0,M0,H0
L1,M1,H1
L2,M2,H2
L3,M3,H3
L4,M4,H4
L5,M5,H5
L6,M6,H6
L7,M7,H7
R12 илиM2
02
03
04
05
R13 илиM3
Data RAM
Data RAM
Data RAM
Data RAM
R14 илиM4
R15 илиM5
R16 илиM6
R17 илиM7
R18 илиH0
R19 илиH1
R1A илиH2
R1B илиH3
R1C илиH4
R1D илиH5
R1E илиH6
R1F илиH7
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
5
IZ7008
Index addressing is possible for all registers (except RO-R7) at setting bit 0 into 1 in the
state register RGS (R7), i.e. at (R7_0)=1.
State register RGS (register R7 with address 0x007).
Bit
Symbol
MFR1
FR3
Description and function
State at supply
switch.
0
R7_7
R7_6
R7_5
R7_4
1 – masking of setting into 1 of interruption request flag
FR1 on timer 1 cleaning
Interruption request flag from timer 3
(set into 1 on timer cleaning front)
Interruption request flag from timer 2
(set into 1 on timer cleaning front)
Interruption request flag from timer 1
(set into 1 on timer cleaning front)
1 – at supply voltage less than reference
0
0
0
FR2
FR1
R7_3
R7_2
SVD
0
0
SVD/LAMP 0- switching-off supply voltage detector
ON
1- switching-on supply voltage detector
0 –sound inhibit (fixing output OUT_AL into 0)
1 – applying on output OUT_AL frequency 4096 Hz
under tune off mode or note frequency in tune foramtion
mode
R7_1
AL_EN
0
R7_0
INDEX
0 –RAM index addressing inhibit, enable direct address-
ing of registers R8-R1F
0
1 – enable RAM index addressing, inhibit direct ad-
dressing of registers R8-R1F
Memory of data, displayed on LCD of maximum size 128 bits is located in address space
from 0x7E8 to 0x7F7 (banks FD, FE). For LCD memory only index addressing is possible. Con-
figuration of LCD memory at multiplexing level at 1/4 is shown in the figure
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
6
IZ7008
Bank
FD
Addres
s
Bit_7
Bit_6
Bit_5
Bit_4
Bit_3
Bit_2
Bit_1
Bit_0
COM
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0x7E8
0x7E9
0x7EA
0x7EB
0x7EC
0x7ED
0x7EE
0x7EF
0x7E0
0x7E1
0x7E2
0x7E3
0x7E4
0x7E5
0x7E6
0x7E7
SEG02 SEG04
SEG02 SEG04
SEG02 SEG04
SEG02 SEG04
SEG01 SEG03
SEG01 SEG03
SEG01 SEG03
SEG01 SEG03
SEG31 SEG29
SEG31 SEG29
SEG31 SEG29
SEG31 SEG29
SEG32 SEG30
SEG32 SEG30
SEG32 SEG30
SEG32 SEG30
SEG06
SEG06
SEG06
SEG06
SEG05
SEG05
SEG05
SEG05
SEG27
SEG27
SEG27
SEG27
SEG28
SEG28
SEG28
SEG28
SEG08
SEG08
SEG08
SEG08
SEG07
SEG07
SEG07
SEG07
SEG25
SEG25
SEG25
SEG25
SEG26
SEG26
SEG26
SEG26
SEG10 SEG12
SEG10 SEG12
SEG10 SEG12
SEG10 SEG12
SEG09 SEG11
SEG09 SEG11
SEG09 SEG11
SEG09 SEG11
SEG23 SEG21
SEG23 SEG21
SEG23 SEG21
SEG23 SEG21
SEG24 SEG22
SEG24 SEG22
SEG24 SEG22
SEG24 SEG22
SEG14
SEG14
SEG14
SEG14
SEG13
SEG13
SEG13
SEG13
SEG19
SEG19
SEG19
SEG19
SEG20
SEG20
SEG20
SEG20
SEG16
SEG16
SEG16
SEG16
SEG15
SEG15
SEG15
SEG15
SEG17
SEG17
SEG17
SEG17
SEG18
SEG18
SEG18
SEG18
Com 1
Com 2
Com 3
Com 4
Com 1
Com 2
Com 3
Com 4
Com 1
Com 2
Com 3
Com 4
Com 1
Com 2
Com 3
Com 4
FE
When multiplex level is 1/3 registers with addresses 0x7EB , 0x7EF, 0x7F3, 0x7F7 can be
used as data memory, and when multiplex level is 1/2 additionally as data memory can be used
the registers with addresses 0x7EA , 0x7E, 0x7F2, 0x7F6.
TIMERS UNIT AND PORT
System registers of timers unit have the addresses 0x7D8- 0x7DD (bank FB), of input-
output unit have the addresses 0x7E0- 0x7E4 (bank FC). For system registers only index
addressing is possible.
Bank N Addres
s
Description
Bit_7 Bit_6
Bit_5
Bit_4 Bit_3
Bit_2
Bit_1 Bit_0
W/R
W/R
0
0x7D8
Timers control register
IN1
T3
IN0
T3
IN1
T2
IN0
T2
CLR
T3
CLR
T2
EN
T3
EN
T2
1
2
3
4
5
0
0x7D9
0x7DA
0x7DB
0x7DC
0x7DB
0x7E0
Timer Т1
Timer Т2
Timer Т3
T1_7 T1_6 T1_5 T1_4 T1_3 T1_2 T1_1 T1_0
T2_7 T2_6 T2_5 T2_4 T2_3 T2_2 T2_1 T2_0
T3_7 T3_6 T3_5 T3_4 T3_3 T3_2 T3_1 T3_0
R
R
R
FB
FC
Setting register Т2
Setting register Т3
Register
KT2_7 KT2_6 KT2_5 KT2_4 KT2_3 KT2_2 KT2_1 KT2_0 W/R
KT3_7 KT3_6 KT3_5 KT3_4 KT3_3 KT3_2 KT3_1 KT3_0 W/R
M1
M0
M1
M0
M1
M0
M1
M0
W/R
settings PORT 1-4
Register
Setting PORT4 Setting PORT3 Setting PORT2 Setting PORT1
M1 M0 M1 M0 M1 M0 M1 M0
Setting PORT8 Setting PORT7 Setting PORT6 Setting PORT5
1
2
0x7E1
0x7E2
W/R
Settings PORT 5-8
Register of flags EN/CLR
1-interruption enable
0-interruption request reset
Register (indicator) of re-
quests for interruption from
bits PORT
EN/CL EN/CL EN/CL EN/CL EN/CL EN/CL EN/CL EN/CL W/R
IR8
IR8
IR7
IR7
IR6
IR6
IR5
IR5
IR4
IR4
IR3
IR3
IR2
IR2
IR1
IR1
3
4
0x7E3
0x7E4
R
R
Register (indicator) of in-
put/output port bits state
НЕ
НЕ
НЕ
НЕ
НЕ
НЕ
НЕ
НЕ
PORT8 PORT7 PORT6 PORT5 PORT4 PORT3 PORT2 PORT1
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
7
IZ7008
ORGANISATION OF INTERRUPTIONS.
The interruptions may be initiated:
а) by external devices from bits РORT1-PORT8;
б) by internal devices (timers T1,T2,T3).
The initial addresses of subprograms of processing interruptions as their priority decrease are
shown in the table.
Address
0x000
0x08F
0x09F
0x0AF
0x0CF
0x0BF
0x0DF
0x0EF
0x0FF
Source of interruption
Supply switching on
Timers 1, 2 and 3 simultaneously
Timers 2 and 3 simultaneously
Timers 1 and 3 simultaneously
Timers 1 and 2 simultaneously
Timer 3
Note
Simultaneously with timers there
may be initiated interruption from
input port which should be taken
into consideration in interrupt ser-
vice routine
Timer 2
Timer 1
Input / output port
Interruptions are executed after complete execution of the command of main program when there
is a request. Interruptions are inhibited after the jump instructions: JMP, JMI and JC, JNC, JZ, JNZ
when executing jump conditions, commands JSR of return from subprogram.
Interruptions from port bits may be initiated if the corresponding bit of interrupt enabling register in
register RFC_2 is program-set into 1.
At the same time, reading the register RFC_3 (read-only) allows to display from which port bits
interrupt requests are called. Interrupt request from any port bit can be reset after executing inter-
rupt service routine by recording 0 into the corresponding bit in the register RFC_2 with the follow-
ing setting of this bit into 1 for enabling thhe further inmterrupt request. Each port bit can be indi-
vidually tuned by presetting bits M1, M0 in the registers RFC_3 and RFC_3 with the following pos-
sible options of internal states.
Bits
Internal
port state
Interrupts
Notes
M1
0
M0
0
OUT ZL (high-impedance 0)
Interrupts from
external actions
inhibited
By mask «programming» internal level ZL
(high-impedance 0) can be disconnected
0
1
OUT L
( “strong” zero)
IN RL (resistive 0)
IN RH
1
1
0
1
Interrupts from
external actions
enabled
Interrupts evocation under high level
Interrupts evocation under low level
(resistive 1)
Mask «programming» can disconnect internal level (ZL, RL,RH) with possible replacement of
them by external resistors.
Reading of the register R FC_4 (read-only) allows to display state of all port bits given either, one
or another external action.
External actions may be the following:
H
– «strong» 1
HR – «weak» 1
– «strong» 0
L
LR – «weak» 0
Z
– high impedance state
State of port bits under all possible combinations of external actions and internal states are shown
in the table
Internal
state
External action
H
1
1
HR
1
L
0
0
LR
0
Z
1
0
IN RH
IN RL
1
0
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
8
IZ7008
OUT L
1
1
0
1
0
0
0
0
0
0
OUT ZL
It's assumed that internal state and external actions are levelized stronger as for external actions.
MC includes three timers-counters T1, T2, T3. All the timers are binary octal counters with
weight 128, 64, 32, 16, 8, 4, 2, 1.
Timer Т1 (register RFB_1 with address 0x7D9 )
Timer Т1 is 8-bit counter with division factor 256 . The frequency of quartz oscillator 32768 Hz is
applied on the counter input.
The counter is for reading only. Data read out on data bus is shown below.
D7
D6
D5
D4
D3
D2
D1
D0
T1_7
T1_6
T1_5
T1_4
T1_3
T1_2
T1_1
T1_0
128 Hz
256 Hz
512 Hz
1024 Hz
2048 Hz
4096 Hz
8192 Hz
16384 Hz
When reading the counter, the problems related to the possibility of reading changeable data, may
occur. For the correct reading, if necessary, reading of data can be done several times in succes-
sion with the following comparison of the results. At the reset when switching on the supply, timer
T1 is cleared (the counter is reset into zero state).
After execution of HLT command timer counter is reset and fixed in zero state (in zero state input
OCSI is also fixed) until the next program starts (from external actions on IN_PORT).
At ripple-through carry of timer T1 which happens with period of 1/128 sec, FrT1 "short" pulse is
formed, it sets interrupt request flag FR1 in the state register R7 into 1 (bit 4 of the state register
R7), if masking bit of timer MFR1 (bit 7 of the state register R7) is reset into 0.
When setting masking bit of oftimer MFR1 into 1 state of flag FR1 doesn't change, but its setting
during the next ripple-through carry on timer counter T1 is inhibited. There can be done repro-
gramming of T1 (by mask "programming") ensuring setting of FR1 flag with periods of 1/32 sec (at
LCD multiplex 1/4) or 6/256 sec (at LCD multiplex 1/3). The data read-out on data bus can be the
following:
D7
D6
D5
D4
D3
D2
D1
D0
T1_7
32 Hz
T1_6
T1_5
T1_4
T1_3
T1_2
T1_1
T1_0
256 Hz
( 64 Hz)
512 Hz
1024 Hz
2048 Hz
4096 Hz
8192 Hz
16384 Hz
or:
D7
D6
D5
D4
D3
D2
D1
D0
T1_7
T1_6
T1_5
T1_4
T1_3
T1_2
T1_1
T1_0
256/6 Hz
256 Hz
512 Hz
1024 Hz
2048 Hz
4096 Hz
8192 Hz
16384 Hz
Timers Т2, Т3 (registers RFB2, RFB3 with addresses 0x7DA and 0x7DB)
Timers Т2, Т3 are 8-bit counters with programmable division factor from setting registers КТ2 (reg-
ister RFB4 with address 0x7DC), КТ3 (register RFB5 with address 0x7DE) . Division factors are
programmed from maximum value 256 (when recording 0x00 into registers КТ2, КТ3) to the value
equal to the contents of registers КТ2, КТ3 (from 0х01 to 0хFF except mode of notes frequency
forming in timer T2).
The counters are for reading only. When reading count register the problems related to the possi-
bility of reading changeable data may occur. For the correct reading, if necessary, reading of the
data can be done several times in succession with the following comparing of the results.
When the code equal to the contents of registers KT2, KT3 (or at ripple-through carry when
recording 0x00 into registers KT2, KT3), timers T2, T3 are cleared (except mode of notes fre-
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
9
IZ7008
quency forming in timer 2) and "short" pulses FrT2, FrT3 setting respectively interrupt request flag
FR2 into 1 (bit 5 of the state register R7) and Interrupt request flag FR3 in the states register R7
(bit 6 of the state register R7) are formed.
Flag FR2 is not set into mode of notes frequency forming in timer T2 and in mode when
"short" pulse FrT2 of timer T2 clearing is input signal of timer T3.
The timers are controlled by timers control register RFBO (address 0x7D8)
Description of RFBO control register bits:
Bit
Symbol
Description
After
reset
RFBO_7
IN1-T3
7,6 bits choose source of timer T3 input signal
00 – signal of ripple-through carry of timer T1
0
(«short» pulse FrT1)
01 – output Т1_3 of timer Т1 (2048Hz)
10 – signal of clearing timer Т2
RFBO_6
RFBO_5
IN0-T3
IN1-T2
(«short» pulse FrT2), in this mode setting of flag FR2 is inhibited
11 – external signal IN6 (output 06 when disconnecting SEG 01 by mask)
5,4 bits choose source of timer T2 input signal
0
0
00 – signal of ripple-through carry of timer Т1
(«short» pulse FrT1)
01 – output Т1_3 of timer Т1 (2048Hz)
10 – signal 65565 Hz (notes frequency forming mode), in this mode setting of FR2 flag
is inhibited
RFBO_4
RFBO_3
IN0-T2
0
0
11 –external signal IN6, IN7, IN8 (from outputs 06, 07 or 08 when disconnecting corre-
sponding SEG 01, SEG 02, SEG 03 by mask)
CLR-T3
1-clearing (reset and zero code fixation) of T3 timer counter, reset of FR3 flag
(except mode, when T3 is clocked by FrТ2 signal; in this mode RFBO_3 and RFBO_1
shoose source of input signal Т2: 00-IN7, 01-IN6 ,1X –IN8)
1-clearing (reset and zero code fixation) of T2 timer counter, reset of FR2 flag and T3
timer with reset of FR3 flag (when T3 is clocked by FrТ2 signal)
1/0- (count enable) /(count inhibit) Т3 (except mode when Т3 is clocked by FrТ2 signal;
in this mode RFBO_3 and RFBO_1 shoose source of input signal Т2: 00-IN7, 01-IN6
,1X –IN8))
RFBO_2
RFBO_1
CLR-T2
EN-T3
0
0
RFBO_0
EN-T2
1/0- (count enable) / (count inhibit) Т2 (always) and (count enable) / (count inhibit) Т3
(when T3 is clocked by FrТ2 signal )
0
Timer Т2 can be used in the mode of notes frequency forming for tunes synthesis. The
mode is selected when recording code «10» into 5,4 bits of RFBO control register (IN1-T2=1, IN0-
T2 = 0 ) and timer count enabling.
RFBO_7
IN1-T3
RFBO_6
IN0-T3
RFBO_5
IN1-T2
RFBO_4
IN0-T2
RFBO_3
CLR-T3
RFBO_2
CLR-T2
RFBO_1
EN-T3
RFBO_0
EN-T2
X
X
1
0
X
0
X
1
In this mode setting of interrupt request flag FR2 in the state register R7 is inhibited. Signal of
65565 Hz is applied on counter input.. Notes frequency is formed on counter output (output
T2_7) and can be applied on external output "AL" at the set into 1 flag AL_EN in the state
register R7.
Seven lower counter bits count in the beginning of zero semi-period of note. After reaching
the code equal to the contents of 7 lower bits of KT2 register, 7 lower bits of the counter are
cleared but the highest bit is switched into logic 1 and then the note second (unit) semi-
period is counted in the same way.
As a result on output the frequency of 65565Hz/2N is formed, where N is number from 2 to
127, set in 7 lower bits of register KT2. To form notes period with accuracy to one period of
input frequency 65565 Hz the following possibility is forseen. When setting in register KT2
the higher bit of KT register in logic 1 when counting the second (unit) semi-period at code
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
10
IZ7008
reaching, equal to the contents of 7 lower bits of register KT2, 1-6 bits of timer are set into 0,
but the lowest bit is set into 1 and, thus, the following zero semi-period of note is "cut" for one
period of input signal. In this case the frequency equal to 65565 Hz / (2N-1) can be formed.
Formed notes frequency (output T2_7) can be supplied on external output "AL" at set into 1
flag AL_EN in the state register R7.
On output "AL" output T2_7 is also applied (at set into 1 flag AL_EN) at the following state of
timers control register RFBO:
RFBO_7
IN1-T3
1
RFBO_6
IN0-T3
0
RFBO_5
IN1-T2
1
RFBO_4
IN0-T2
1
RFBO_3
CLR-T3
X
RFBO_2
CLR-T2
0
RFBO_1
EN-T3
X
RFBO_0
EN-T2
1
In this mode T2 is clocked by external signal (RC-oscillator), Т3 by clearing signal Т2 («short»
pulse FrT2) , injection of the signal from output T2_7 on output «AL» is used for testing (meas-
urement of RC-oscillator frequency).
Configuration of timers may by the following
Contents of register
RFB0
Input Т2
Interrupt
Input Т3
Interrupt
Note
request flag
request flag
FR2
FR3
0
00000000
0(no count)
FrT1
2048 Hz
FrT1
2048 Hz
65536 Hz
65536 Hz
65536 Hz
0
0(no count)
FrT1
State after system reset
0000C3C2E3E2
0001C3C2E3E2
0100C3C2E3E2
0101C3C2E3E2
0010C3C2E3E2
0110C3C2E3E2
1110C3C2E3E2
1010C3C2E3E2
1000XC32XE32
1001XC32XE32
0011C3C2E3E2
0111C3C2E3E2
1111C3C2E3E2
10110C320 E32
10110C321 E32
10111C32X E32
+
+
+
FrT1
+
+
2048 Hz
2048 Hz
FrT1
+
+
+
Set. inhibited
Set. inhibited
Set. inhibited
+
Tune mode
2048 Hz
IN6
+
+
Inhibited combination
FrT1
2048 Hz
0(no count)
0(no count)
0(no count)
IN7
Set. inhibited
Set. inhibited
FrT2
FrT2
+
+
+
+
+
+
+
+
-
FrT1
-
2048 Hz
IN6
-
Set. inhibited
Set. inhibited
Set. inhibited
FrT2
IN6
IN8
FrT2
FrT2
E2 , E3 - bits (count enable) /(count inhibit) of timer 2 or 3
E32 bit (count enable) /(count inhibit) of timers 2 and 3 simultaneously
С2 , С3 - bits of clearing timer 2 or 3
С32 bit of clearing timers 2 and 3 simultaneously
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
11
IZ7008
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
12
IZ7008
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
13
IZ7008
IZ7008 pins description
Contact pad
No.
Symbol
Description
01
02
03
04
05
06
GND
IN3
OSCO
OSCI
COM1
SEG1/
IN6
SEG2/
IN7
SEG3/
IN8
Common output
Control input
Output for connecting oscillator crystal
Input for connecting oscillator crystal
Output of LCD common electrode control
Output of LCD sign electrode control /
Control input*
Output of LCD sign electrode control /
Control input*
Output of LCD sign electrode control /
Control input*
07
08
09
10
11
12
13
SEG4
SEG5
SEG6
SEG7
SEG8
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
14
15
16
17
18
19
20
21
SEG9
SEG10
SEG11
SEG12
SEG13
SEG14
SEG15
COM3/
SEG16
P2/
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD sign electrode control
Output of LCD common electrode control /
Output of LCD sign electrode control
Voltage transducer output/
22
EL/
Electroluminiscent backlighting control output/
LCD sign electrode ocntrol output/
Output of LCD common electrode control *
SEG02/
COM3
23
P1/
Voltage transducer output/
IND/
Electroluminiscent backlighting control output/
LCD sign electrode ocntrol output/
Output of LCD common electrode control *
LCD sign electrode ocntrol output//
LCD sign electrode ocntrol output/*
Control input
COM3/
SEG16/
SEG01
IN2
24
25
26
27
28
IN1
Control input
Supply voltage output from voltage source
Alarm clock control output
LCD common electrode control output/
Alarm clock control Inverse output*
LCD sign electrode control output/
LCD common electrode control output*
LCD sign electrode control output
LCD sign electrode control output
UCC1
AL
COM2/
NAL
29
SEG16/
COM2
SEG17
SEG18
30
31
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
14
IZ7008
Table continued
Contact pad
No.
Symbol
Description
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
SEG19
SEG20
SEG21
SEG22
SEG23
SEG24
SEG25
SEG26
SEG27
SEG28
SEG29
SEG30
SEG31
SEG32
COM4/
SEG32
IN5
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD sign electrode control output
LCD common electrode control output /
LCD sign electrode control output *
Control input
47
48
IN4
Control input
LCD - liquid crystal display
*
- function to be chosen by coding
42
41
40
39
38
37
36
35
34
33
32
31
43
44
30
29
28
27
26
25
24
23
22
21
20
19
45
46
47
48
01
02
03
04
05
06
IZ7008
09
07
08
10
11
14
15
16
17
18
13
12
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
15
IZ7008
Chip size: 3420±30 х 2430±30 mkm.
Chip width: 460±20 mkm.
Contact pad size 100х100 mkm in «Metallization layer»
Contact pad
No.
Co-ordinates (mkm)
Contact pad No.
Co-ordinates (mkm)
X
Y
X
Y
106
106
106
106
106
106
419
643
867
1091
1315
1539
1763
1987
2211
2435
2659
2883
3216
3216
3216
3216
3216
3216
1068
891
721
552
382
212
105
105
105
105
105
105
105
105
105
105
105
105
275
444
614
784
953
1123
3216
3216
3216
3216
3216
3216
2902
2678
2454
2230
2006
1782
1558
1334
1110
886
662
438
106
106
106
106
106
106
1292
1462
1632
1801
1971
2140
2224
2224
2224
2224
2224
2224
2224
2224
2224
2224
2224
2224
2078
1908
1739
1569
1400
1230
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Korzhenevskogo 12, Minsk, 220064, Republic of Bel-
arus
Fax:
+375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
16
厂商 型号 描述 页数 下载

INTEGRAL

IZ7007 电路的电子计步器 - ergmeter[ Circuit for electron pedometer - ergmeter ] 8 页

INTEGRAL

IZ7010 电路是否电子计步器 - 测力计[ CIRCUIT FOR ELECTRON PEDOMETER - ERGOMETER ] 14 页

INTEGRAL

IZ7406 六反相缓冲器/带集电极开路高压输出驱动程序[ Hex Inverter Buffers/Drivers with Open-Collector High-Voltage Outputs ] 4 页

INTEGRAL

IZ74HC157A 四2输入数据选择器/多路复用器[ Quad 2-Input Data Selectors/Multiplexer ] 6 页

INTEGRAL

IZ74HC174A 六路D触发器与普通时钟和复位高性能硅栅CMOS[ Hex D Flip-Flop with Common Clock and Reset High-Performance Silicon-Gate CMOS ] 6 页

INTEGRAL

IZ74HC21A 两个4输入与门[ Dual 4-Input AND Gate ] 5 页

INTEGRAL

IZ74HC221AZ 双单稳多谐振荡器[ DUAL MONOSTABLE MULTIVIBRATOR ] 7 页

INTEGRAL

IZ74HCT21A 两个4输入与门[ Dual 4-Input AND Gate ] 5 页

INTEGRAL

IZ74HCT27A 三路3输入NOR门[ Triple 3-Input NOR Gate ] 5 页

INTEGRAL

IZ74HCU04 六角无缓冲变频器高性能硅栅CMOS[ Hex Unbuffered Inverter High-Performance Silicon-Gate CMOS ] 6 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.204731s
