SMD Type
Diodes
PIN Diode for VHF,UHF,AGC Applications
1SV248
Features
Very small-sized package facilitates high-density mounting and permits
1SV248-applied equipment to be made smaller.
Small interterminal capacitance (C=0.23pF typ).
Small forward series resistance (rs=4.5
typ).
Absolute Maxim um Ratings Ta = 25
Param eter
Reverse Voltage
Sym bol
Value
50
Unit
V
VR
IF
Forward Current
50
m A
m W
Allowable Power Dissipation
Junction Tem perature
Storage tem perature
P
100
Tj
125
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
Conditions
Min
50
Typ
Max
Unit
V
VR
IR
IR = 10
A
Reverse Current
VR = 50 V
IF = 50 mA
0.1
4.5
A
Forward Voltage
VF
C
0.95
0.23
V
Interterminal Capacitance
Series Resistance
VR = 50 V, f = 1 MHz
pF
rs
IF = 10 mA,f = 100 MHz
Marking
Marking
FV
1
