SMD Type
Diodes
PIN Diode for VHF,UHF,AGC Applications
1SV266
SOT-23
Unit: mm
+0.1
2.9
-0.1
+0.1
0.4
-0.1
Features
3
Small sized package facilitates high-denstiy mounting
and permits 1SV266-applied equipment to be made smaller.
Small interterminal capacitance (C=0.23pF typ).
Small forward series resistance (rs=2.5 typ).
1
2
+0.1
0.95
-0.1
+0.05
0.1
-0.01
+0.1
1.9
-0.1
1.Base
2.Emitter
3.collector
Absolute Maximum Ratings Ta = 25
Parameter
Reverse Voltage
Symbol
Value
50
Unit
V
VR
IF
Forward Current
50
mA
mW
Allowable Power Dissipation
Junction Temperature
Storage temperature
P
150
Tj
125
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
Conditions
IR = 10
Min
50
Typ
Max
0.1
Unit
V
VR
IR
A
Reverse Current
VR = 50 V
IF = 50 mA
A
Forward Voltage
VF
C
0.91
0.23
4.0
V
Interterminal Capacitance
VR = 50 V, f = 1 MHz
IF = 5 mA,f = 100 MHz
IF = 10 mA,f = 100 MHz
pF
Series Resistance
rs
2.5
Marking
Marking
JV
1
