SMD Type
Diodes
Silicon Epitaxial Planar Diode
1SV302
SOD-323
Unit: mm
+0.1
1.7
-0.1
+0.05
0.85
-0.05
Features
+0.1
2.6
-0.1
High Capacitance Ratio:C2V/C25V=17.5(Typ.)
Low Series Resistance:rs=1.05 (Typ.)
Useful for Small Size Tuner
1.0max
0.475
0.375
Absolute Maximum Ratings Ta = 25
Parameter
Reverse Voltage
Symbol
VR
Value
30
Unit
V
Peak Reverse Voltage
Junction Temperature
Storage Temperature Range
VRM
Tj
V
35(RL = 10K
125
)
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
VR
Conditions
Min
30
Typ
Max
Unit
V
IR = 1
A
Reverse Current
Capacitance
IR
VR = 28 V
10
51
nA
C2V
f = 1 MHz;VR = 2 V
f = 1 MHz;VR = 25 V
42
2.1
17
47
pF
C25V
C2V/C25V
rs
2.6
3.1
Capacitance Ratio
Series Resistance
Note :
17.5
1.05
VR = 5V, f = 470 MHz
1.25
Available in matched group for capacitance to 2.5%.
C(Max.)-C(Min.)
0.025
C(Min.)
(VR=2~25V)
Marking
Marking
TT
1
