SMD Type
Diodes
Silicon Epitaxial Planar Diode
1SV328
SOD-323
Unit: mm
+0.1
1.7
-0.1
+0.05
0.85
-0.05
Features
+0.1
2.6
-0.1
High Capacitance Ratio:C1V/C4V=2.8(Typ.)
Low Series Resistance:rs=0.55 (Typ.)
Useful for Small Size Tuner
1.0max
0.475
0.375
Absolute Maximum Ratings Ta = 25
Parameter
Reverse Voltage
Symbol
VR
Value
10
Unit
V
Junction Temperature
Tj
125
Storage Temperature Range
Tstg
-55 to +125
Electrical Characteristics Ta = 25
Parameter
Reverse Voltage
Symbol
VR
Conditions
Min
Typ
Max
Unit
V
10
IR = 1
A
Reverse Current
Capacitance
IR
VR = 10 V
3
nA
C1V
C4V
C1/C4V
rs
f = 1 MHz;VR = 1 V
f = 1 MHz;VR = 4 V
5.7
1.85
2.7
6.7
pF
2.45
Capacitance Ratio
Series Resistance
2.8
VR = 1V, f = 470 MHz
0.55
0.7
Note
1.Signal level when capacitance is measured:Vsig = 100mVrms
Marking
Marking
V2
1
