JXE75
Quartz Crystal · JXE75
Surface Mount Quartz Crystal
actual size
Features
■
RoHS compliant
■
ceramic/ceramic package
General Data
ESR (series resistance Rs)
type
JXE75
frequencꢀ
in MHz
vibration ESR max.
ESR tꢀp.
in Ω
40
frequencꢀ range
6.00 ~ 60.0 MHz
28.00 ~ 125.0 MHz
73.32 ~ 170.0 MHz
25.00 ~ 50.0 MHz
20 ppm ~ 50 ppm
12 pF ~ 32 pF or series
< 7 pF
( fund. AT-cut )
( 3rd OT AT-cut )
( 5th OT AT-cut )
( fund. BT-cut )
mode
in Ω
80
6.00 ~ 7.999
8.00 ~ 9.999
fund. - AT
fund. - AT
on request
60
30
10.0 ~ 15.999 fund. - AT
16.0 ~ 60.000 fund. - AT
50
20
frequencꢀ tolerance at 25 °C
load capacitance CL
shunt capacitance Co
storage temperature
drive level max.
40
15
28.0 ~ 125.00 3rd OT - AT
73.32 ~ 170.0 5th OT - AT
60
35
-40 °C ~ +125 °C
100 µW
Ω
Ω
aging
<
5 ppm first ꢀear
25.0 ~ 50.000 fund. - BT
50
20
Frequency Stability vs. Temperature
Marking
frequencꢀ with load capacitance code
30 ppm
50 ppm
100 ppm
150 ppm
200 ppm
companꢀ code / date code / internal code
-20 °C ~ +70 °C
-40 °C ~ +85 °C
-40 °C ~ +105 °C
-40 °C ~ +125 °C
STD.
T1
O
•
date code:
example:
ꢀear/month
O
•
5A = 2005 Januarꢀ
T2
O
O
O
Jan.
A
Febr. Mar.
Apr.
D
Maꢀ
E
June
F
T3
O
O
B
C
standard
on request
•
Julꢀ
G
Aug.
H
Sept.
J
Oct.
K
Nov.
L
Dec.
M
O
Order Information
stabilitꢀ vs.
temp. range
in ppm
frequencꢀ
in MHz
tꢀpe
load capacitance
stabilitꢀ at 25 °C
in ppm
option
Q
in pF
Quartz
6.0 ~ 170.0 MHz
JXE75/1 standard
JXE75/2
JXE75/3
12 pF standard
12 pF ~ 32 pF
S for series
50 ppm standard
see table
blank = -20°C ~ +70°C
FU = fundamental AT-cut
3OT = 3rd overtone AT-cut
5OT = 5th overtone AT-cut
T1 = -40°C~+85°C
T2 = -40°C~+105°C
T3 = -40°C~+125°C
LF = Pb free contact
pins / pads
Example: Q 28.0-JXE75/1-12-30/30-FU
T h e p u l s e o f p r o g r e s s
•
•
•
•
Jauch Quartz GmbH Telephone: (+49) 77 20 / 9 45-0 Telefax: (+49) 77 20 / 9 45-100 Internet: www.jauch.de e-mail: info@jauch.de · 04/2005
