16.0-36.0 GHz Up-Converter
QFN, 4x4mm
December 2007 - Rev 18-Dec-07
U1010-QH
Features
Integrated Balanced Mixer, LO Buffer and LO Doubler
+23.0 dBm Input Third Order Intercept (IIP3)
+2.0 dBm LO Drive Level
4x4mm QFN Package
100% RF and DC Testing
General Description
Mimix Broadband’s 16.0-36.0 GHz GaAs packaged
up-converter has an input third order intercept point
of +22.0 dBm and 10.0 dB of conversion loss.The
device consists of a balanced resistive pHEMT mixer,
LO buffer amplifier and LO doubler packaged in an in
an industry standard, fully molded 4x4mm QFN
package. The device includes on-chip ESD protection
structures and DC by-pass capacitors to ease the
implementation and volume assembly of the
packaged part. This device is well suited for
Millimeter-wave Point-to-Point Radio, LMDS, SATCOM
and VSAT applications.
Absolute Maximum Ratings
Parameter
Units Min. Max.
Drain Voltage Supply (Vdd)
Drain Current (Ids)
V
-
-
-
-
6
350
5
mA
dBm
dBm
Input Power (Pin) IF
Input Power (Pin) LO
Storage Temperature (Tstg)
10
°C -55 +150
Operating Backside Temperature (Tb) °C -45 +85
ESD –Machine Model (ESD_MM)
ESD –Human Body Model (ESD_HBM)
MSL Level (MSL)
V
50
-
-
V
200
MSL2
Electrical Characteristics (AmbientTemperatureT = 25 oC)
Parameter
Frequency Range (RF/LO)
Units
GHz
GHz
dB
dBm
dBm
dB
Min.
16
DC
Typ.
Max.
36
3.5
Frequency Range (IF)
Conversion Loss (CL)
Input Third Order Intercept (IIP3)
LO Input Drive
RF Input Return Loss
LO Input Return Loss
IF Input Return Loss
2xLO Leakage at RF
10
23
2
15
15
15
-20
-30
5
-0.2
-0.8
-2
140
80
50
dB
dB
dBm
dBm
VDC
VDC
VDC
VDC
mA
1xLO Leakage at RF
Drain Bias Voltage (Vd1,2)
Gate Bias Voltage (Vg1)
Gate Bias Voltage (Vg2,3)
Gate Bias Voltage (Vss)
Supply Current (Id1)
Supply Current (Id2)
Supply Current (Iss)
mA
mA
