2STN2540_08

型号：

2STN2540_08

描述：

低压快速开关PNP功率双极晶体管[ Low voltage fast-switching PNP power bipolar transistor ]

品牌：

STMICROELECTRONICS[ ST ]

页数：

9 页

PDF大小：

205 K

下载PDF手册
2STN2540
Low voltage fast-switching PNP power bipolar transistor
Features
■ Very low collector-emitter saturation voltage
■ High current gain characteristic
■ Fast switching speed
4
■ Surface mounting device in medium power
3
SOT-223 package
2
1
Applications
SOT-223
■ Emergency lighting
■ LED
■ CCFL drivers (back lighting)
■ Voltage regulation
■ Relay driver
Figure 1.
Internal schematic diagram
Description
The device is a PNP transistor manufactured
using new “PB-HCD” (Power Bipolar High Current
Density) technology. The resulting transistor
shows exceptional high gain performances
coupled with very low saturation voltage.
Table 1.
Order code
2STN2540
Device summary
Marking
Package
SOT-223
Packaging
N2540
Tape and reel
January 2008
Rev 3
1/9
www.st.com
9
Electrical ratings
2STN2540
1
Electrical ratings
Table 2.
Symbol
Absolute maximum rating
Parameter
Value
Unit
V
Collector-base voltage (I = 0)
-40
-40
V
V
CBO
E
V
Collector-emitter voltage (I = 0)
CEO
B
V
Emitter-base voltage (I = 0)
-6
V
EBO
C
I
Collector current
-5
A
C
I
Collector peak current (t < 5ms)
-10
A
CM
P
I
Base peak current (t < 5ms)
-2
A
BM
P
P
Total dissipation at T
= 25 °C
1.6
W
°C
°C
tot
amb
T
Storage temperature
-65 to 150
150
stg
T
Max. operating junction temperature
J
Table 3.
Symbol
Thermal data
Parameter
Value
Unit
(1)
Thermal resistance junction-amb
__max
78
°C/W
R
thj-amb
1. Device mounted on PCB area of 1cm2
2/9
2STN2540
Electrical characteristics
2
Electrical characteristics
(T
= 25 °C unless otherwise specified)
case
Table 4.
Symbol
Electrical characteristics
Parameter
Test conditions
Min.
Typ. Max. Unit
Collector cut-off current
V
I
= -30 V
CB
-0.1
-0.1
µA
µA
CBO
(I =0)
E
Emitter cut-off current
I
V
= -5 V
EB
EBO
(I =0)
C
I = -0.5 A I = -5 mA
-120
-180
-200
-450
mV
mV
mV
mV
-80
C
B
(1)
I = -1 A
I = -10 mA
-120
-140
-350
V
V
C
B
Collector-emitter
saturation voltage
CE(sat)
I = -2 A
I = -200 mA
C
B
I = -5 A
I = -500 mA
C
B
Base-emitter saturation
voltage
(1)
(1)
I = -5 A
I = -500 mA
-1.3
V
V
C
B
BE(sat)
V
= -2 V I = -2 A
Base-emitter on voltage
-1.25
V
CE
C
BE(on)
I = -0.5 A
V
V
V
V
= -2 V
= -2 V
= -2 V
= -2 V
250
200
150
50
C
CE
CE
CE
CE
I = -1 A
C
(1)
DC current gain
h
FE
I = -2 A
C
I = -5 A
C
I = 0
V
= -10 V
CB
Collector-base
capacitance
E
C
80
pF
CBO
f = 1 MHz
I = -1 A _
V
= -10 V
CC
C
Resistive load
Turn-on time
Storage time
Fall time
t
-I = I = -0.1 A
75
426
62
ns
ns
ns
on
B1
B2
t
T
= 30 µs
s
p
t
f
1. Pulsed duration = 300 µs, duty cycle ≤1.5%
3/9
Electrical characteristics
2STN2540
2.1
Electrical characteristics (curves)
Figure 2.
Figure 4.
Figure 6.
Output characteristics
Figure 3.
DC current gain
Collector-emitter saturation Figure 5.
voltage
Base-emitter saturation
voltage
Base-emitter on voltage
Figure 7.
Resistive load switching
times
4/9
2STN2540
Electrical characteristics
Figure 8.
Resistive load switching
times
Figure 9.
Capacitance
2.2
Test circuit
Figure 10. Resistive load switching test circuit
1) Fast electronic switch
2) Non-inductive resistor
5/9
Package mechanical data
2STN2540
3
Package mechanical data
In order to meet environmental requirements, ST offers these devices in ECOPACK®
packages. These packages have a Lead-free second level interconnect. The category of
second level interconnect is marked on the package and on the inner box label, in
compliance with JEDEC Standard JESD97. The maximum ratings related to soldering
conditions are also marked on the inner box label. ECOPACK is an ST trademark.
ECOPACK specifications are available at: www.st.com
6/9
2STN2540
Package mechanical data
SOT-223 mechanical data
mm.
typ
DIM.
min.
max.
1.80
0.1
A
A1
B
0.02
0.60
2.90
0.24
6.30
0.70
3.00
0.26
6.50
2.30
4.60
3.50
7.00
0.85
3.15
0.35
6.70
B1
c
D
e
e1
E
3.30
3.70
7.30
H
6.70
o
V
10
0046067_L
7/9
Revision history
2STN2540
4
Revision history
Table 5.
Date
Document revision history
Revision
Changes
23-Oct-2003
03-Nov-2006
14-Jan-2008
1
2
3
Initial release
Added new graphics: fig.2, fig. 7, fig.8, fig.9.
Document status promoted from preliminary data to datasheet.
8/9
2STN2540
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZE REPRESENTATIVE OF ST, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS, WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS “AUTOMOTIVE
GRADE” MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2008 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
9/9
