Product data sheet
Characteristics
XCSM4115L1
safety limit switch XCSM - metal - rotary lever -
2 NC + 2 NO - cable 1 m
Main
Range of product
Preventa Safety detection
Safety limit switch
Product or component
type
Component name
Design
XCSM
Miniature
Metal
Material
Head type
Rotary head
Protection technology
Plastic protective cover, secured by 5-lobe socket
head safety screw
Type of approach
Type of operator
Lateral approach
Thermoplastic roller lever
1 NC + 1 NC + 1 NO + 1 NO
Contacts type and
composition
Contact operation
Snap action
Complementary
Electrical connection
Cable length
Pre-cabled
1 m
Cable composition
9 x 0.34 mm²
By 30° cam
By the body
4
Switch actuation
Fixing mode
Number of poles
Positive opening
With NC contact
10000000 cycles
0.5 N.m
Mechanical durability
Minimum torque for tripping
Positive opening minimum torque
Minimum actuation speed
Maximum actuation speed
Contact code designation
0.1 N.m
0.01 m/min
1.5 m/s
B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN 60947-5-1
B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix
A
R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN 60947-5-1
R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix
A
[Ui] rated insulation voltage
300 V conforming to UL 508
400 V (pollution degree 3) conforming to IEC 60947-5-1
300 V conforming to CSA C22.2 No 14
[Uimp] rated impulse withstand voltage
IEC 60664 4 kV
IEC 60947-1 4 kV
Maximum resistance across terminals
Short-circuit protection
Repeat accuracy
Body material
Head material
Depth
25 MOhm conforming to IEC 60255-7 category 3
6 A cartridge fuse type gG (gl)
0.05 mm on the tripping points
Zamak
Zamak
34 mm
94 mm
30 mm
0.205 kg
Height
Width
Net weight
Feb 8, 2021
1
