XCS
Controller
Input
Other Technical Data
Voltage
18-72V DC
Dimensions
(WxHxD)
483/584 x 44 x 274mm
(19/23 x 1.75 x 10.8in.)
Current
<200 mA at 48V, <400 mA at 24V
Weight
4.94kg (11lbs.)
Interface
Display
Operating
Temperature
-40 to +65°C
-50 to +85°C
2x20 character LCD with backlight
Storage
Temperature
RS485 Data Bus for communication
with a maximum of 128 rectifiers and
128 sub-controllers
Internal
Communication
Storage:
ETS 300 019-2-1
Environment
Transport:
Operation:
ETS 300 019-2-2
ETS 300 019-2-3
RS232 Serial interface for
remote control from a PC with
PowCom software
Internal
Communication
Green LED - Power ON
Yellow LED - System warning message
Battery
Indications
Controls
Red LED -
System failure message
An optional feature that allows
voltage controlled disconnection
of batteries.
Battery
Disconnection
Four pushbutton controls
Manual time controlled or
automatic boost charging with
adjustable time and voltage levels.
Signal
Collection
Wide range of interface units with
analog and digital input/outputs
Boost Charging
Battery Test
Software
Site upgradeable by EEPROM flash
Multiple language options
Automatic or manual testing of
batteries up to four times per year
with a 10 test memory. Variables
include: test duration, end voltage,
and amount of Ah’s to be
Language
Alarms
discharged during test.
The last 40 events are saved and
include a time and date stamp.
Alarm History
Optional tool that measures
batteries for early detection of
thermal runaway. Allows for
separate measurements of up to
12 parallel battery branches, each
divided into four blocks.
6 potential free change-over alarm
contacts. Two open collector outputs
for LVD operation.
Symmetry
Measurement
Alarm
Contacts
Alarms
High System Voltage
Low System Voltage
Load/ Battery Disc.
Mains Error
Distribution Fuse Failure
Battery Failure
Module Failure
Battery Temp. Alarm
Symmetry Fault
Battery Fuse Failure
High Load
Battery Fuse Disc.
Urgent Module Failure
Communication Failure
Partial Load Disc.
1*
2*
4*
3*
4*
6*
5*
6*
6*
4*
5*
5*
4*
5*
4*
Allows continuous adjustment of
output voltage according to
battery temperature. Features
include adjustable compensation
factor and separate thresholds for
high temperature alarms.
Temperature
Compensation
Charging
Optional feature that allows
voltage or time controlled
disconnection of non-essential
load.
PLD
Monthly logging of essential
battery parameters, including
temperature, temp. hours, current,
charging voltage, and symmetry
voltage. Parameters are stored
for 5 years.
Enhanced
Battery
Monitoring
* All alarms are indicated using an LED and displayed in
the LCD. The numbers represent an example of alarm
routing. Sixteen additional alarms are available and are
configurable by changing the PCS EEPROM.
Note: All specifications are subject to change without notification.
