Applications
OV16885-4C
¬
Smartphones
¬
PC Multimedia
¬
Video Conferencing
Ordering Information
¬
OV16885-GA5A-4C
(4-cell color, chip probing, 150 µm backgrinding,
reconstructed wafer with good die)
Product Features
¬
¬
¬
16MP @ 30 fps, 4K2K @ 60 fps
(1.0 µm non-Bayer output)
¬
¬
supports horizontal and
vertical subsampling
4MP @ 60 fps, 1080p @ 120 fps
(2.0 µm Bayer output)
programmable controls for:
- frame rate
- mirror and flip
- cropping
- windowing
Product Specifications
supports dynamic defect pixel
correction (DPC) in Bayer output mode
¬
active array size: 4672 x 3504
¬
¬
maximum image transfer rate:
- 4672 x 3504: 30 fps
- 3840 x 2160: 60 fps
- 2336 x 1752: 60 fps
- 1080p: 120 fps
- 720p: 180 fps
- 800 x 480: 240 fps
¬
¬
automatic black level calibration (ABLC)
¬
up to 4-lane MIPI TX interface with
speed up to 1.6 Gbps/lane
¬
power supply:
- core: 1.2V
- analog: 2.8V
- I/O: 1.8V
total embedded one-time
programmable (OTP) memory:
2048 bytes, 896 bytes for customer
use, remaining bytes for internal use
¬
¬
¬
programmable I/O drive capability
standard serial SCCB interface
¬
¬
power requirements:
- active: 300 mW
- XSHUTDOWN: <1 µW
max S/N ratio: 37.5 dB
@ 4C binning mode
¬
supports typical images sizes:
- 4672 x 3504
supports output formats:
- 10-bit RAW RGB
- DPCM 10-8 compression
- 3840 x 2160
temperature range:
- operating: -30°C to +85°C junction
temperature
¬
¬
dynamic range: 72 dB@ 16x gain
- 2336 x 1752
- 1920 x 1080
¬
¬
¬
two on-chip phase lock loops (PLLs)
built-in temperature sensor
-
dark current: 4 e /sec
- 1280 x 720
- stable image: 0°C to +60°C junction
temperature
@ 60°C junction temperature
- 800 x 480
¬
¬
¬
¬
scan mode: progressive
typical module size: 8.5 x 8.5 x 4.9 mm
¬
¬
¬
¬
input clock frequency: 6 ~ 27 MHz
lens size: 1/3.06"
pixel size: 1.0 µm x 1.0 µm
image area: 4741.63 µm x 3564.29 µm
lens chief ray angle: 34.2° non-linear
die dimensions:
- COB: 5690 µm x 4050 µm
- RW: 5740 µm x 4120 µm
-
sensitivity: 13.8 Ke /Lux-sec
@ 4C binning mode
Functional Block Diagram
OV16885-4C
image sensor core
sensor
interface
column
sample/hold
processor
MCP/N
MDP/N[3:0]
10-bit
ADC
AMP
array
temperature
sensor
gain
control
control register bank
SCCB interface
PLLs
PLL
timing generator and system control logic
