Applications
OV10625
¬
Automotive
- pedestrian detection
- lane-departure warning
- lane keeping assist
- blind spot detection
- traffic signal recognition
Ordering Information
¬
OV10625-N02V-1A-Z
(RCCC, lead-free, 102-pin aCSP™, rev 1A, in tray)
Product Features
¬
support for image size: WVGA, VGA,
QVGA and any cropped size
¬
¬
¬
supported output formats: RAW
horizontal and vertical sub-sampling
¬
¬
¬
¬
¬
high dynamic range
high sensitivity
Product Specifications
serial camera control bus (SCCB)
for register programming
¬
active array size: 752 x 548
¬
lens size:
- VGA: 1/3.7"
- WVGA: 1/3.2"
safety features
¬
external frame synchronization
capability
¬
power supply:
- core: 1.425 ~ 1.575V
- analog: 3.14 ~ 3.47V
- I/O: 1.7 ~ 3.47V
low power consumption
¬
¬
¬
lens chief ray angle: 9°
¬
¬
¬
¬
50/60 Hz flicker cancellation
parallel 16-bit DVP output
image sensor processor functions:
- automatic exposure/gain control
- lens correction
- defective pixel cancelation
- HDR combination and tone mapping
- automatic black level correction
input clock frequency: 6 ~ 27 MHz
¬
¬
power requirements:
- active: TBD
- standby: TBD
maximum image transfer rate:
60 fps full resolution
embedded temperature sensor
one time programmable (OTP) memory
temperature range:
¬
¬
¬
¬
¬
¬
¬
¬
dynamic range: ~120 dB
sensitivity: 15 V/lux-sec
scan mode: progressive
shutter: rolling shutter
- operating: -40°C to +105°C
sensor ambient temperature and
-40°C to +125°C junction temperature
(operating sensor junction
temperatures above +60°C
may result in degraded image quality)
¬
¬
output interfaces:
16-bit parallel DVP
maximum exposure interval: TBD
pixel size: 6 µm x 6 µm
output formats: up to 20-bit combined
RAW, separated 8-/10-bit RAW
image area: 4608 µm x 3384 µm
package dimensions:
- aCSP: 7310 µm x 7810 µm
Functional Block Diagram
OV10625
sensor core
processor
output
interface
column
sample
& hold
10-bit
ADC
+
AMP
+
ISP
-
-
D[15:0]
BLC
pixel
array
AEC
AGC
ADRC
control
register bank
temperature sensor
SPI master
interface
SCCB
interface
OSC
PLLs
timing generator and system control logic
