Applications
OV16880
¬
Smartphones
¬
¬
Digital Video Camcorders (DVC)
PC Multimedia
¬
Digital Still Cameras (DSC)
Ordering Information
¬
OV16880-GA5A-1B
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
Product Features
¬
automatic black level calibration (ABLC)
¬
¬
programmable I/O drive capability
¬
programmable controls for frame rate,
mirror and flip, cropping, and windowing
up to 1/2/4-lane LVDS interface with
speed up to 1.5 Gbps/lane
Product Specifications
¬
¬
support for dynamic DPC cancellation
¬
embedded 13kbits (1664 bytes) of
one-time programmable (OTP) memory
for customer use
supports output formats:
10-bit RAW RGB
¬
active array size: 4672 x 3504
¬
maximum image transfer rate:
- 4672x3504: 30 fps
- 4672x2628: 30 fps
- 2336x1752: 60 fps
- 1920x1080: 90 fps
- 1280x720: 120 fps
¬
¬
¬
¬
¬
¬
interleave row HDR output
support for high speed AF
support for PDAF
¬
power supply:
- core: 1.2V
- analog: 2.8V
- I/O: 1.8V
¬
¬
supports horizontal and vertical
subsampling
supports typical images sizes:
4672x3504, 4672x2628, 2336x1752,
1920x1080, 1280x720
-
¬
¬
power requirements:
- active: 300 mW
- standby: 6 mA
¬
¬
¬
¬
¬
¬
sensitivity: 3200 e /lux-sec
three on-chip phase lock loops (PLLs)
programmable I/O drive capability
built-in temperature sensor
max S/N ratio: 36.8 dB
¬
¬
¬
supports 2x2 binning
- XSHUTDN: 3 µA
dynamic range: 72 dB @ 16x gain
scan mode: progressive
standard serial SCCB interface
temperature range:
- operating: -30°C to +85°C junction
temperature
- stable image: 0°C to +60°C junction
temperature
up to 4-lane MIPI TX interface with
speed up to 1.5 Gbps/lane
pixel size: 1.0 µm x 1.0 µm
-
dark current: 4 e /sec
¬
¬
¬
¬
output formats: 10-bit RGB RAW
lens size: 1/3.06"
@ 60°C junction temperature
¬
¬
image area: 4741.632 µm x 3564.288 µm
lens chief ray angle: 34.2° non-linear
input clock frequency: 6 ~ 64 MHz
die dimensions:
- COB: 5640 µm x 4560 µm
- RW: 5690 µm x 4610 µm
Functional Block Diagram
OV16880
image sensor core
sensor
processor
image output
interface
column
sample/hold
MCP/N
MDP/N[3:0]
AMP
10-bit
ADC
array
temperature
sensor
gain
control
control register bank
SCCB interface
PLLs PLL
timing generator and system control logic
