OV10823
¬
Security and Surveillance
Ordering Information
Product Features
¬
OV10823-H75A
(color, lead-free, 75-pin CSP5)
¬
¬
¬
1.4 µm x 1.4 µm pixel with OmniBSI-2™
¬
¬
¬
¬
support 1x2 binning, 2x2 binning
temperature sensor
optical size of 1/2.6"
programmable controls for frame rate,
mirror and flip, cropping, windowing,
and panning
standard serial SCCB interface
up to 4-lane MIPI serial output
interface
Product Specifications
¬
¬
image quality controls:
black level callibration
¬
12K bits of embedded one-time
programmable (OTP) memory
¬
active array size: 4320 x 2432
¬
maximum exposure interval:
1 frame -4 T
line
support for output formats:
10-bit RAW RGB data and
DPCM 10-8 compression
¬
power supply:
¬
¬
¬
two on-chip phase lock loop (PLL)
programmable I/O drive capability
support for black sun cancellation
- core: 1.2V ±5%
- analog: 2.7 ~ 3.0V
- I/O: 1.7 ~ 3.0V
¬
maximum image transfer rate:
- 10.5MP (4320x2432): 30 fps
- 2.6MP (2160x1216): 60 fps
¬
support for video or
snapshot operations
¬
¬
power requirements:
- active: 296 mW
- standby: 200 µA
- XSHUTDOWN: 5 µA
¬
¬
¬
¬
¬
¬
¬
scan mode: progressive
shutter: rolling shutter
sensitivity: 1010 mV/lux-sec @ 530 nm
max S/N ratio: 36.4 dB
temperature range:
- operating: -30°C to +70°C junction
temperature
- stable image: 0°C to +60°C junction
temperature
dynamic range: 71.5 dB @ 8x gain
pixel size: 1.4 µm x 1.4 µm
¬
output formats: 10-bit RAW RGB data
and DPCM 10-8 compression
-
dark current: 10 e /s
@ 60°C junction temperature
¬
¬
¬
lens size: 1/2.6"
¬
¬
image area: 6092.8 µm x 3449.6 µm
die dimensions: 7630 µm x 5980 µm
lens chief ray angle: 0°
input clock frequency: 6 ~ 27 MHz
Functional Block Diagram
OV10823
image sensor core
sensor
processor
image output
interface
column
sample/hold
MCP/MCN
MDP/N[3:0]
10-bit
ADC
array
AMP
temperature
sensor
gain
control
control register bank
SCCB slave interface
PLLs
PLL
timing generator and system control logic
