Applications
OV13A1Q
¬
Smartphones
¬
PC Multimedia
¬
Video Conferencing
Ordering Information
¬
OV13A1Q-GA5A-Z
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
Product Features
¬
13MP @ 30 fps, 4K2K @ 30 fps
¬
programmable controls for:
- frame rate
- mirror and flip
- cropping
- windowing
¬
supports dynamic defect pixel
correction (DPC) in Bayer output mode
Product Specifications
¬
¬
automatic black level calibration (ABLC)
¬
¬
up to 4-lane MIPI TX interface with
speed up to 1.2 Gbps/lane
total embedded one-time
programmable (OTP) memory:
1536 bytes
¬
active array size: 4224 x 3136
¬
lens chief ray angle: 36.7° non-linear
standard serial SCCB interface with
speed up to 1 MHz
(when clock input is >10 MHz)
¬
power supply:
- core: 1.2V
- analog: 2.8V
- I/O: 1.8V
¬
maximum image transfer rate:
- 4224x3136: 30 fps
- 4224x2376: 30 fps
- 2112x1568: 60 fps
- 2112x1188: 60 fps
- 1408x792: 60 fps
¬
supports typical images sizes:
- 4224x3136
- 4224x2376
¬
¬
supports output formats:
- 10-bit RAW RGB
- DPCM 10-8 compression
- 2112x1568
¬
temperature range:
- 2112x1188
- operating: -30°C to +85°C junction
temperature
- stable image: 0°C to +60°C junction
temperature
- 1408x792
¬
¬
¬
¬
input clock frequency: 6 ~ 64 MHz
scan mode: progressive
long exposure time of
up to 30 seconds
¬
supports horizontal and
vertical subsampling
¬
¬
built-in temperature sensor
¬
¬
pixel size: 1.008 µm x 1.008 µm
lens size: 1/3.4"
image area: 4290.05 µm x 3193.34 µm
¬
¬
programmable I/O drive capability
two on-chip phase lock loops (PLLs)
typical module size:
7.5 x 7.5 x <4.5 mm
die dimensions:
- COB: 5364 µm x 3627 µm
- RW: 5414 µm x 3677 µm
Functional Block Diagram
OV13A1Q
image sensor core
sensor
processor
interface
column
sample/hold
MCP/N
MDP/N[3:0]
10-bit
ADC
AMP
array
temperature
sensor
gain
control
control register bank
SCCB interface
PLLs
PLL
timing generator and system control logic
