4N65K-MT
Power MOSFET
ELECTRICAL CHARACTERISTICS (TC =25°С, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
Drain-Source Leakage Current
BVDSS
IDSS
VGS = 0 V, ID = 250μA
650
V
VDS = 650 V, VGS = 0 V
VGS = 30 V, VDS = 0 V
10
μA
Forward
Reverse
100 nA
-100 nA
V/°С
Gate-Source Leakage Current
IGSS
VGS = -30 V, VDS = 0 V
ID=250μA, Referenced to 25°C
△BVDSS/△TJ
Breakdown Voltage Temperature Coefficient
ON CHARACTERISTICS
Gate Threshold Voltage
Static Drain-Source On-State Resistance
DYNAMIC CHARACTERISTICS
Input Capacitance
0.6
VGS(TH)
RDS(ON)
VDS = VGS, ID = 250μA
2.0
4.0
1.77 2.50
V
VGS = 10 V, ID = 2.2A
Ω
CISS
COSS
CRSS
430 750 pF
VDS = 25 V, VGS = 0V,
Output Capacitance
60
6
90
11
pF
pF
f = 1MHz
Reverse Transfer Capacitance
SWITCHING CHARACTERISTICS
Turn-On Delay Time
tD(ON)
tR
tD(OFF)
tF
44
60
ns
Turn-On Rise Time
VDD = 30V, ID = 0.5A,
RG = 25Ω (Note 1, 2)
50 100 ns
80 130 ns
Turn-Off Delay Time
Turn-Off Fall Time
45
17
70
20
ns
nC
nC
nC
Total Gate Charge
QG
VDS= 50V,ID= 1.3A,
Gate-Source Charge
QGS
QGD
4.9
3.7
VGS= 10V (Note 1, 2)
Gate-Drain Charge
SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS
Drain-Source Diode Forward Voltage
Maximum Continuous Drain-Source Diode
Forward Current
VSD
VGS = 0 V, IS = 4.4A
1.4
4.4
V
A
IS
Maximum Pulsed Drain-Source Diode
Forward Current
ISM
17.6
A
Notes: 1. Pulse Test: Pulse width ≤ 300μs, Duty cycle≤2%
2. Essentially independent of operating temperature
