IXTA180N10T
IXTP180N10T
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 Outline
A
(TJ = 25C, Unless Otherwise Specified)
E
E1
C2
L1
L2
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
70
110
S
D1
D
4
H
A1
1
2
3
Ciss
Coss
Crss
6900
923
pF
pF
pF
b
b2
L3
c
e
e
0.43 [11.0]
0
162
0.34 [8.7]
td(on)
tr
td(off)
tf
33
54
42
31
ns
ns
ns
ns
0.66 [16.6]
A2
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 25A
RG = 3.3 (External)
1 - Gate
2,4 - Drain
3 - Source
0.20 [5.0]
0.10 [2.5]
0.12 [3.0]
0.06 [1.6]
Qg(on)
Qgs
151
39
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 25A
Qgd
45
RthJC
RthCH
0.31C/W
C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
180
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = 25A, VGS = 0V, Note 1
450
TO-220 Outline
A
E
oP
A1
0.95
H1
Q
trr
IRM
QRM
72
5.1
0.18
ns
A
μC
IF = 90A, VGS = 0V
D2
E1
D
-di/dt = 100A/s, VR = 50V
D1
A2
EJECTOR
PIN
L1
L
3X b
e
c
Notes: 1. Pulse test, t 300s; duty cycle, d 2%.
e1
3X b2
2. On through-hole packages, RDS(on) Kelvin test contact
location must be 5mm or less from the package body.
1 - Gate
2,4 - Drain
3 - Source
IXYS reserves the right to change limits, test conditions, and dimensions.
