IXTA230N075T2-7
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 (7-lead) (IXTA..7) Outline
(TJ = 25°C, unless otherwise specified)
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
50
85
S
Ciss
Coss
Crss
10.5
1165
125
nF
pF
pF
td(on)
tr
td(off)
tf
23
18
33
15
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2Ω (External)
Qg(on)
Qgs
178
53
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Pins: 1 - Gate
2, 3 - Source
4 - Drain
Qgd
41
RthJC
0.31 °C/W
5,6,7 - Source
Tab (8) - Drain
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min. Typ.
Max.
230
900
1.3
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, Pulse width limited by TJM
IF = 100A, VGS = 0V, Note 1
trr
66
4.4
ns
A
IF = 115A, VGS = 0V
IRM
QRM
-di/dt = 100A/μs
VR = 37V
145
nC
Notes: 1. Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
2. On through-hole packages, RDS(on) Kelvin test contact
location must be 5mm or less from the package body.
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS reserves the right to change limits, test conditions, and dimensions.
