Minimum size of detected object
Status LED
Cylinder diameter 2.5 mm
Flat bar 1 mm wide
1 LED (green) supply on
1 LED (yellow) output state
Current consumption
Maximum switching current
Voltage drop
Switching frequency
Delay first up
Delay response
Delay recovery
Marking
25 mA
100 mA with overload and short-circuit protection
< 1 V
<= 125 Hz
20 ms
2 ms
2 ms
CE
Threaded length
Height
1.5 in (38 mm)
0.47 in (12 mm)
0.47 in (12 mm)
1.97 in (50 mm)
0.02 lb(US) (0.011 kg)
Width
Depth
Product weight
Environment
Standards
IEC 60947-5-2
Product certifications
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-4...149 °F (-20...65 °C)
-40...176 °F (-40...80 °C)
+/-1 mm conforming to IEC 60068-2-6 10...55 Hz
30 gn in all 3 axes 11 ms conforming to IEC 60068-2-27
8 kV level 4 conforming to IEC 61000-4-2
9.14 V/yd (10 V/m) level 3 conforming to IEC 61000-4-3
1 kV level 3 conforming to IEC 61000-4-4
Shock resistance
Resistance to electrostatic discharge
Resistance to electromagnetic fields
Resistance to fast transients
Ordering and shipping details
Category
22490 - SENSORS-ULTRASONIC (XX5,6)
Discount Schedule
GTIN
DS2
003389119129145
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.20000000000000001
Y
Country of origin
US
Offer Sustainability
California proposition 65
- - - - - - - Substance 1
- - - - - - - Substance 2
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
Contractual warranty
Warranty period
18 months
