UYGT801-S

型号：

UYGT801-S

品牌：

SEOUL[ Seoul Semiconductor ]

页数：

13 页

PDF大小：

329 K

下载PDF手册
Specification
UYGT801-S
SSC
Customer
Drawn
Approval
Approval
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
UYGT801-S
1. Features
2. Absolute Maximum Ratings
3. Electro-Optical Characteristics
4. Characteristic Graph
5. Reliability
6. Color & binning
7. Outline Dimension
8. Packing
9. Soldering
10. Precaution for use
11. Handling of Silicone Resign LEDs
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
UYGT801-S
Features
UYGT801-S
Description
This surface-mount LED
comes in PLCC standard
package dimension. It has a
substrate made up of a molded
plastic reflector sitting on top
of a bent lead frame. The die is
attached within the reflector
cavity and the cavity is
• Industry Standard
PLCC SMT package
• High brightness
using AlInGaP dice
technologies
• Available in multiple
colors
encapsulated by epoxy or
silicone
The package design coupled
with careful selection of
component materials allow
these products to perform with
high reliability in a larger
temperature range -40℃ to
100℃. The high reliability
feature is crucial to Automotive
interior and Indoor ESS.
• High volume, high
reliability
Applications
• Interior automotive
• Electronic Signs and
Signals
• Office Automation,
Electrical Appliances,
Industrial Equipment
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
1. Features
• Yellow-Green colored SMT package
• Material AlInGaP
• Suitable for all SMT assembly methods
Suitable for all soldering methods
• RoHS Compliant
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
2. Absolute maximum ratings
Parameter
Symbol
Pd
Value
Unit
mW
mA
mA
V
Power Dissipation
Forward Current
75
IF
30
*2
Peak Forward Current
Reverse Voltage
IFM
90
VR
5
Operating Temperature
Storage Temperature
Topr
Tstg
-40 ~ +100
-40 ~ +100
oC
oC
[1] Care is to be taken that power dissipation does not exceed the absolute maximum rating of the product.
[2] IFM was measured at Tw≤1 msec of pulse width and D≤1/10 of duty ratio.
[3] LED’s properties might be different from suggested values like above and below tables if operation condition
will be exceeded our parameter range.
3. Electro-Optical characteristics
Parameter
Forward Voltage
Symbol
Condition
IF =20mA
VR=5V
Min
1.7
-
Typ
2.1
-
Max
2.5
10
105
-
Unit
V
VF
IR
Reverse Current
μA
Luminance Intensity *1
Peak Wavelength
IV
IF =20mA
IF =20mA
IF =20mA
IF =20mA
IF =20mA
30
-
90
mcd
nm
nm
nm
deg.
λP
λd
Δλ
576
572
18
Dominant Wavelength
Spectral Bandwidth 50%
Viewing Angle *2
568
-
574
-
2θ
-
120
-
½
*1. The luminous intensity IV was measured at the peak of the spatial pattern which may not be aligned with the mechanical axis of
the LED package. Luminous Intensity Measurement allowance is ±10%
*2. 2θ½ is the off-axis where the luminous intensity is 1/2 of the peak intensity.
*3. A tolerance of ±0.05V on forward voltage measurements
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
4. Characteristic Graph
Relative Luminous Intensity vs Forward Current
Forward Current vs. Forward Voltage
(Ta=25 OC )
(Ta=25 OC )
102
101
100
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
1.8
1.9
2.0
2.1
2.2
0
5
10
15
20
25
30
35
Forward Current IF [mA]
Forward Voltage VF (V)
Forward Current Derating Curve
Radiation Diagram
(Ta=25 OC )
40
30
20
10
0
0
30
-30
60
-60
90
-90
-40
-20
0
20
40
60
80
100
120
O
Ambient Temperature TA [ C]
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
5 Reliability
Number
of
Damage
Duration
/ Cycle
Item
Reference
Test Condition
Ta =-40oC (30MIN) ~ 100oC (30MIN)
100 Cycle
100 Cycle
Thermal Shock
EIAJ ED-4701
EIAJ ED-4701
0/22
0/22
Ta =-40oC (30MIN) ~ 25oC (5MIN)
~ 100oC (30MIN) ~ 25oC (5MIN)
Temperature
Cycle
High Temperature
Storage
1000
Hours
Ta =100oC
EIAJ ED-4701
EIAJ ED-4701
EIAJ ED-4701
0/22
0/22
High Temperature
High Humidity
Storage
1000
Hours
Ta =85oC, RH=85%
Low Temperature
Storage
1000
Hours
Ta =-40oC
0/22
0/22
Operating
Endurance Test
Internal
Reference
1000
Hours
Ta =25oC, IF =30mA
High Temperature
High Humidity
Life Test
Internal
Reference
300
Hours
Ta =85oC, RH=85%, IF =15mA
0/22
High Temperature
Life Test
Internal
Reference
1000
Hours
Ta =100oC, IF =5mA
Ta =-40oC, IF =20mA
1KV at 1.5kΩ; 100pF
0/22
0/22
0/22
Low Temperature
Life Test
Internal
Reference
1000
Hours
MIL-STD-
883D
ESD(HBM)
3 Time
Criteria for Judging the Damage
Criteria for Judgement
MIN MAX
Item
Symbol
Condition
Forward Voltage
Reverse Current
VF
IR
IF =20mA
VR=5V
-
-
USL*1 × 1.2
USL*1 × 2.0
Luminous
Intensity
IV
IF =20mA
LSL*2 × 0.5
-
Note : *1 USL : Upper Standard Level
*2 LSL : Lower Standard Level
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
6. Color & Binning
● UYGT801-S BINNING
RANK NAME
VF [V]
IV [mcd]
75 ~ 85
85 ~ 95
95 ~ 105
75 ~ 85
85 ~ 95
95 ~ 105
75 ~ 85
85 ~ 95
95 ~ 105
Wd [nm]
A
B
C
D
E
F
570 ~ 572
568 ~ 570
572 ~ 574
1.7~2.5
G
H
I
J
570 ~ 572
568 ~ 570
572 ~ 574
K
L
30 ~ 75
[Note] All measurements were made under the standardized environment of SSC.
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
7.outline dimension
Recommended Solder Pattern
1.9
2.8
0.8
2.2
0.15
Anode
Cathode
Cathode Mark
2.2
( Tolerance: ±0.2, Unit: mm )
8. packing
1.55
± 0.05
4.0±0.1
0.22±0.05
2.0±0.05
1.0±0.1
8°
3.1±0.1
2.22±0.1
11.4±0.1
9.0 ±0.3
+0
-3
180
2.0 ±0.2
LABLE
13±0.2
30°
10
22
(1) Quantity : 2000pcs/Reel
(2) Cumulative Tolerance : Cumulative Tolerance/10 pitches to be ±0.2mm
(3) Adhesion Strength of Cover Tape : Adhesion strength to be 0.1-0.7N when the cover tape is turned off from
the carrier tape at the angle of 10º to the carrier tape
(4) Package : P/N, Manufacturing data Code No. and quantity to be indicated on a damp proof Package
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
● Reel Packing Structure
Reel
RANK:
XXX
QUANTITY : XXXX
LOT NUMBER : XXXXXXXXXX
PART NUMBER :
XXXXXX
SEOUL SEMICONDUCTOR CO., LTD.
HUMIDITY INDICATOR
DESI PAK
Aluminum Vinyl Bag
RANK:
XXX
QUANTITY : XXXX
LOT NUMBER : XXXXXXXXXX
PART NUMBER :
XXXXXX
SEOUL SEMICONDUCTOR CO., LTD.
Outer Box Structure
Material : Paper(SW3B(B))
SIZE (mm)
TYPE
a
c
b
245 220 142
7inch
SIDE
1
c
RANK:
XXX
1
QUANTITY : XXXX
LOT NUMBER : XXXXXXXXXX
TOP LED
a
RoHS
b
PART NUMBER :
XXXXXX
SEOUL SEMICONDUCTOR CO., LTD.
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
9. soldering
(1) Lead Solder
Lead Solder
Lead Solder
o
o
2.5~5 C / sec.
240 C Max.
10 sec. Max.
Pre-heat
120~150℃
Pre-heating
120~150 C
Pre-heat time
120 sec. Max.
240℃ Max.
10 sec. Max.
o
60sec. Max.
Above 200 C
2.5~5 C / sec.
o
Peak-Temperature
Soldering time Condition
120sec. Max.
(2) Lead-Free Solder
Lead-frame Solder
o
Lead Free Solder
150~200℃
o
1~5 C / sec.
260 C Max.
10 sec. Max.
Pre-heat
Pre-heating
Pre-heat time
120 sec. Max.
260℃ Max.
o
60sec. Max.
Above 220 C
o
150~200
C
1~5 C / sec.
o
Peak-Temperature
Soldering time Condition
10 sec. Max.
120sec. Max.
(3) Hand Soldering conditions
Do not exceed 4 seconds at maximum 315ºC under soldering iron.
(4) The encapsulated material of the LEDs is silicone.
Precautions should be taken to avoid the strong pressure on the encapsulated part.
So when using the chip mounter, the picking up nozzle that does not affect the silicone
resign should be used.
(5) It is recommended that the customer use the nitrogen reflow method.
(6) Repairing should not be done after the LEDs have been soldered.
(7) Reflow soldering should not be done more than two times.
In the case of more than 24 hours passed soldering after first, LEDs will be damaged.
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
10. precaution for use
(1) Storage
In order to avoid the absorption of moisture, it is recommended to store in a dry box (or a
desicator) with a desiccant. Otherwise, to store them in the following environment is
recommended.
Temperature : 5ºC ~30ºC Humidity : maximum 70%RH
(2) Attention after open.
LED is correspond to SMD, when LED be soldered dip, interfacial separation may affect
the light transmission efficiency, causing the light intensity to drop.
Attention in followed; Keeping of a fraction
Temperature : 5 ~ 40ºC Humidity : less than 10%
(3) In the case of more than 4 week passed after opening or change color of indicator
on desiccant, components shall be dried 10-12hr. at 60±5ºC.
(4) Silver plating might be tarnished in the environment that contains corrosive gases
and materials. Also any product that has tarnished lead might be decreased the
solder-ability and optical-electrical properties compare to normal ones.
Please do not expose the product in the corrosive environment during the storage.
(5) Any mechanical force or any excess vibration shall not be accepted to apply during
cooling process to normal temperature after soldering.
(6) Quick cooling shall be avoided.
(7) Components shall not be mounted on warped direction of PCB.
(8) Anti radioactive ray design is not considered for the products.
(9) This device should not be used in any type of fluid such as water, oil, organic
solvent etc. When washing is required, IPA should be used.
(10) When the LEDs are illuminating, operating current should be decided after considering
the ambient maximum temperature.
(11) The LEDs must be soldered within seven days after opening the moisture-proof packing.
(12) Repack unused products with anti-moisture packing, fold to close any opening and then
store in a dry place.
(13) The appearance and specifications of the product may be modified for improvement
without notice.
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
11. Handling of Silicone Resin LEDs
(1) During processing, mechanical stress on the surface should be minimized as much as
possible. Sharp objects of all types should not be used to pierce the sealing compound.
(2) In general, LEDs should only be handled from the side. By the way, this also applies
to LEDs without a silicone sealant, since the surface can also become scratched.
(3) When populating boards in SMT production, there are basically no restrictions
regarding the form of the pick and place nozzle, except that mechanical pressure on the
surface of the resin must be prevented.
This is assured by choosing a pick and place nozzle which is larger than the LED’s
reflector area.
(4) Silicone differs from materials conventionally used for the manufacturing of LEDs.
These conditions must be considered during the handling of such devices. Compared to
standard encapsulants, silicone is generally softer, and the surface is more likely to
attract dust.
As mentioned previously, the increased sensitivity to dust requires special care
during processing. In cases where a minimal level of dirt and dust particles cannot be
guaranteed, a suitable cleaning solution must be applied to the surface after the
soldering of components.
(5) SSC suggests using isopropyl alcohol for cleaning. In case other solvents are used, it
must be assured that these solvents do not dissolve the package or resin.
Ultrasonic cleaning is not recommended. Ultrasonic cleaning may cause damage to the
LED.
Rev. 00
September 2010
www.seoulsemicon.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
厂商 型号 描述 页数 下载

SEOUL

 		UYGT801 表面贴装LED[ surface-mount LED ] 10 页

SEOUL

 		UYGT801S-KM [ 暂无描述 ] 10 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.265767s
