IXTK17N120L
IXTX17N120L
Symbol
Test Conditions
Characteristic Values
TO-264 (IXTK) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • IDSS, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
3.5
5.0
6.5
S
Ciss
Coss
Crss
8300
520
90
pF
pF
pF
td(on)
tr
td(off)
tf
42
31
ns
ns
ns
ns
Resistive Switching Times
V
GS = 15V, VDS = 0.5 • VDSS, ID = 0.5 • IDSS
110
83
RG = 2Ω (External)
Qg(on)
Qgs
155
41
nC
nC
nC
VGS = 15V, VDS = 0.5 • VDSS, ID = 0.5 • IDSS
Qgd
60
RthJC
RthCS
0.18 °C/W
°C/W
0.15
Safe Operating Area Specification
Symbol
SOA
Test Conditions
Characteristic Values
Min.
Typ.
Max.
VDS = 800V, ID = 0.3A, TC = 60°C, tP = 3s
240
W
PLUS 247TM (IXTX) Outline
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
17
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
50
IF = 17A, VGS = 0V, Note 1
1.5
V
IF = IS, -di/dt = 100A/μs, VR = 100V
1830
ns
Terminals: 1 - Gate
2 - Drain (Collector)
3 - Source (Emitter)
4 - Drain (Collector)
Note: 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
Dim.
Millimeter
Min. Max.
Inches
Min. Max.
A
A1
A2
4.83
2.29
1.91
5.21
2.54
2.16
.190 .205
.090 .100
.075 .085
b
b1
b2
1.14
1.91
2.92
1.40
2.13
3.12
.045 .055
.075 .084
.115 .123
C
D
E
0.61
20.80 21.34
15.75 16.13
0.80
.024 .031
.819 .840
.620 .635
e
5.45 BSC
.215 BSC
L
L1
19.81 20.32
.780 .800
.150 .170
3.81
4.32
Q
R
5.59
4.32
6.20
4.83
.220 0.244
.170 .190
