IXTT140N075L2HV
IXTH140N075L2
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 60A, Note 1
Gate Input Resistance
50
65
80
S
RGi
1.24
Ciss
Coss
Crss
9300
2190
750
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
26
83
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
100
33
RG = 2 (External)
Qg(on)
Qgs
275
40
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
108
RthJC
RthCS
0.23 C/W
C/W
TO-247
0.21
Safe Operating Area Specification
Symbol
SOA
Test Conditions
Characteristic Values
Min.
Typ.
Max.
VDS = 75V, ID = 4.35A, TC = 75C, Tp = 5s
326
W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
140
560
1.4
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, pulse width limited by TJM
IF = 100A, VGS = 0V, Note 1
trr
IRM
QRM
200
14.0
1.4
ns
A
μC
IF = 70A, -di/dt = 100A/s,
VR = 37.5V, VGS = 0V
Note:
1. Pulse test, t 300s; duty cycle, d 2%.
