IXTN40P50P

型号:

IXTN40P50P

品牌:

LITTELFUSE[ LITTELFUSE ]

页数:

6 页

PDF大小:

124 K

PolarPTM
Power MOSFET
VDSS = - 500V
ID25 = - 40A
IXTN40P50P
D
S
RDS(on)
230m
P-Channel Enhancement Mode
Avalanche Rated
G
S
miniBLOC, SOT-227
E153432
S
Symbol
VDSS
Test Conditions
Maximum Ratings
G
TJ = 25C to 150C
TJ = 25C to 150C, RGS = 1M
- 500
- 500
V
V
VDGR
VGSS
VGSM
Continuous
Transient
20
30
V
V
S
D
ID25
IDM
TC = 25C
TC = 25C, Pulse Width Limited by TJM
- 40
A
A
- 120
G = Gate
D = Drain
S = Source
IA
EAS
TC = 25C
TC = 25C
- 40
3.5
A
J
Either Source Terminal at miniBLOC
can be used as Main or Kelvin Source.
dv/dt
PD
IS IDM, VDD VDSS, TJ 150C
TC = 25C
10
V/ns
W
890
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
C
C
C
Features
International Standard Package
miniBLOC, with Aluminium Nitride
Isolation
VISOL
50/60 Hz, RMS
IISOL 1mA
t = 1 minute
t = 1 second
2500
3000
V~
V~
Rugged PolarPTM Process
Avalanche Rated
Md
Mounting Torque
Terminal Connection Torque
1.5/13
1.3/11.5
Nm/lb.in
Nm/lb.in
Low Package Inductance
Weight
30
g
Advantages
Easy to Mount
Space Savings
High Power Density
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
- 500
- 2.0
Typ.
Max.
Applications
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = - 250A
VDS = VGS, ID = -1mA
VGS = 20V, VDS = 0V
VDS = VDSS, VGS = 0V
V
V
High-Side Switches
Push Pull Amplifiers
DC Choppers
Automatic Test Equipment
- 4.5
100 nA
IDSS
- 50 A
TJ = 125C
- 250 A
Current Regulators
RDS(on)
VGS = -10V, ID = 0.5 • ID25, Note 1
230 m
DS99936D(4/15)
© 2015 IXYS CORPORATION, All Rights Reserved
IXTN40P50P
Symbol
Test Conditions
Characteristic Values
SOT-227B (IXTN) Outline
(TJ = 25C, Unless Otherwise specified)
Min.
Typ.
Max.
gfs
VDS = -10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = - 25V, f = 1MHz
23
38
S
Ciss
Coss
Crss
11.5
1150
93
nF
pF
pF
td(on)
tr
td(off)
tf
37
59
90
34
ns
ns
ns
ns
Resistive Switching Times
VGS = -10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 1(External)
Qg(on)
Qgs
205
55
nC
nC
nC
(M4 screws (4x) supplied)
VGS = -10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
75
RthJC
RthCS
0.14C/W
C/W
0.05
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
- 40
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = - 20A, VGS = 0V, Note 1
-160
- 3.0
trr
477
14.5
- 61
ns
C
A
IF = - 20A, -di/dt = -150A/s
QRM
IRM
VR = -100V, VGS = 0V
Note
1: Pulse test, t 300s, duty cycle, d 2%.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or more of the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXTN40P50P
Fig. 1. Output Characteristics @ TJ = 25ºC
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
-40
-35
-30
-25
-20
-15
-10
-5
V
= -10V
- 7V
GS
V
= -10V
- 7V
GS
- 6V
- 6V
- 5V
- 5V
-20
0
0
-5
-10
-15
-25
-30
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = - 20A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
2.4
-40
-35
-30
-25
-20
-15
-10
-5
V
= -10V
- 7V
GS
V
= -10V
GS
2.0
1.6
1.2
0.8
0.4
I
= - 40A
D
- 6V
I
= - 20A
D
- 5V
0
0
-2
-4
-6
-8
-10
-12
-14
-16
-18
-50
-25
0
25
50
75
100
125
150
VDS - Volts
TJ - Degrees Centigrade
Fig. 5. RDS(on) Normalized to ID = - 20A Value vs.
Drain Current
Fig. 6. Maximum Drain Current vs.
Case Temperature
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
-45
-40
-35
-30
-25
-20
-15
-10
-5
V
= -10V
GS
T
J
= 125ºC
T
= 25ºC
-80
J
0
0
-10
-20
-30
-40
-50
-60
-70
-90
-50
-25
0
25
50
75
100
125
150
ID - Amperes
TC - Degrees Centigrade
© 2015 IXYS CORPORATION, All Rights Reserved
IXTN40P50P
Fig. 7. Input Admittance
Fig. 8. Transconductance
70
60
50
40
30
20
10
0
-70
-60
-50
-40
-30
-20
-10
0
T
= - 40ºC
J
25ºC
125ºC
T
J
= 125ºC
25ºC
- 40ºC
-3.5
-4.0
-4.5
-5.0
-5.5
-6.0
-6.5
0
-10
-20
-30
-40
-50
-60
-70
VGS - Volts
ID - Amperes
Fig. 9. Forward Voltage Drop of Intrinsic Diode
Fig. 10. Gate Charge
-140
-120
-100
-80
-60
-40
-20
0
-10
-9
-8
-7
-6
-5
-4
-3
-2
-1
0
V
= - 250V
DS
I
I
= - 20A
D
G
= -1mA
T
J
= 125ºC
T
J
= 25ºC
-0.5
-1.0
-1.5
-2.0
-2.5
-3.0
-3.5
-4.0
0
20
40
60
80
100
120
140
160
180
200
220
VSD - Volts
QG - NanoCoulombs
Fig. 12. Forward-Bias Safe Operating Area
Fig. 11. Capacitance
1000
100,000
10,000
1,000
100
-
f = 1 MHz
R
DS(on)
Limit
C
C
iss
100
-
25µs
100µs
oss
-
10
- 1
1ms
10ms
100ms
T
= 150ºC
= 25ºC
J
C
rss
-30
DC
T
C
Single Pulse
10
-
0.1
0
-5
-10
-15
-20
-25
-35
-40
-
-
10
100
1000
-
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
VDS - Volts
IXTN40P50P
Fig. 13. Maximum Transient Thermal Impedance
1
0.1
0.01
0.001
0.00001
0.0001
0.001
0.01
0.1
1
10
Pulse Width - Seconds
© 2015 IXYS CORPORATION, All Rights Reserved
IXYS REF: T_40P50P(B9) 03-06-08-A
Disclaimer Notice - Information furnished is believed to be accurate and reliable. However, users should independently
evaluate the suitability of and test each product selected for their own applications. Littelfuse products are not designed for,
and may not be used in, all applications. Read complete Disclaimer Notice at www.littelfuse.com/disclaimer-electronics.
