Bu s s m a n n
MAXI S h u n t s
MXS
Dimensions
0.350"
(8.89)
0.142"(3.60)
0.382"
(9.70)
1.092"
(27.73)
0.811"
(20.59)
1.106"
(28.09)
1.350"
(34.29)
0.307"
(7.79)
0.315"
(8.00)
MXS
Removable shunt, used to interconnect 8mm and
2 - 2.8 mm distribution buses.
Maximum current: 8 mm blade
60 Amps
2.8 mm blade 30 Amps each
Part No.
Amp Rating
MXS-30
MXS-60
30
60
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled. This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any prod-
ucts and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been selected, it
should be tested by the user in all possible applications.
Form No. MXS
12-28-98
SB98107
Page 1 of 1
BIF Document: 2077
Rev. A
