IXEH 25N120
IXEH 25N120D1
NPT3 IGBT
IC25
VCES
= 36 A
= 1200 V
VCE(sat)typ = 2.6 V
C
E
C
E
TO-247 AD
G
G
G
C
E
C(TAB)
IXEH25N120
IXEH25N120D1
Features
• NPT3 IGBT
IGBT
Symbol
VCES
Conditions
Maximum Ratings
- positive temperature coefficient of
saturation voltage for easy paralleling
- fast switching
- short tail current for optimized
performance in resonant circuits
• optional HiPerFREDTM diode
- fast reverse recovery
TVJ = 25°C to 150°C
1200
20
V
V
VGES
IC25
IC90
TC = 25°C
TC = 90°C
36
24
A
A
- low operating forward voltage
- low leakage current
• TO-247 package
- industry standard outline
- epoxy meets UL 94V-0
ICM
VCEK
VGE = 15 V; RG = 68 Ω; TVJ = 125°C
60
VCES
A
µs
W
RBSOA, Clamped inductive load; L = 100 µH
tSC
(SCSOA)
VCE = 900V; VGE = 15 V; RG = 68 Ω; TVJ = 125°C
non-repetitive
10
Ptot
TC = 25°C
200
Applications
• AC drives
• DC drives and choppers
• Uninteruptible power supplies (UPS)
• switched-mode and resonant-mode
power supplies
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min.
typ. max.
• inductive heating, cookers
VCE(sat)
IC = 25 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
2.6
3.2
3.2
V
V
VGE(th)
ICES
IC = 0.6 mA; VGE = VCE
4.5
6.5
V
VCE = VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.2 mA
mA
0.2
IGES
VCE = 0 V; VGE
=
20 V
200 nA
td(on)
tr
td(off)
tf
Eon
Eoff
205
105
320
175
4.1
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 600 V; IC = 20 A
VGE = 15 V; RG = 68 Ω
1.5
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600 V; VGE = 15 V; IC = 20 A
1.2
100
nF
nC
RthJC
0.63 K/W
© 2005 IXYS All rights reserved
1 - 4
