IXTP16N50PM

型号：

IXTP16N50PM

品牌：

IXYS[ IXYS CORPORATION ]

页数：

4 页

PDF大小：

182 K

下载PDF手册
Advance Technical Information
PolarHVTM Power
MOSFET
VDSS = 500V
ID25 = 7.5A
RDS(on) ≤ 420mΩ
IXTP16N50PM
(Electrically Isolated Tab)
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
OVERMOLDED
(IXTP...M) OUTLINE
Symbol
Test Conditions
Maximum Ratings
VDSS
VDGR
TJ = 25°C to 150°C
TJ = 25°C to 150°C, RGS = 1 MΩ
500
500
V
V
VGSS
VGSM
Continuous
Transient
± 30
± 40
V
V
Isolated Tab
G
D
S
ID25
IDM
TC = 25°C
TC = 25°C, Pulse Width Limited by TJM
7.5
35
A
A
G = Gate
S = Source
D = Drain
IA
EAS
TC = 25°C
TC = 25°C
16
750
A
mJ
dv/dt
PD
IS ≤ IDM, VDD ≤ VDSS, TJ =150°C
TC = 25°C
10
75
V/ns
W
Features
TJ
TJM
Tstg
- 55 ... +150
150
- 55 ... +150
°C
°C
°C
ꢀPlastic Overmolded Tab for Electrical
Isolation
ꢀInternational Standard Package
ꢀAvalanche Rated
TL
TSOLD
1.6 mm (0.062 in.) from Case for 10 s
Plastic Body for 10 s
300
260
°C
°C
ꢀFast Intrinsic Diode
ꢀLow Package Inductance
Md
Mounting Torque
1.13/10 Nm/lb.in.
Weight
2.5
g
Advantages
ꢀHigh Power Density
ꢀEasy to Mount
Symbol
Test Conditions
Characteristic Values
ꢀSpace Savings
(TJ = 25°C, Unless Otherwise Specified)
Min.
500
3.0
Typ.
Max.
BVDSS
VGS(th)
VGS = 0V, ID = 250μA
VDS = VGS, ID = 250μA
V
V
Applications
5.5
ꢀSwitched-Mode and Resonant-Mode
Power Supplies
IGSS
IDSS
VGS = ±30V, VDS = 0V
±100 nA
ꢀDC-DC Converters
VDS = VDSS, VGS= 0V
5 μA
50 μA
ꢀLaser Drivers
ꢀAC and DC Motor Drives
ꢀRobotics and Servo Controls
TJ = 125°C
RDS(on)
VGS = 10V, ID = 8A, Note 1
420 mΩ
© 2009 IXYS CORPORATION, All Rights Reserved
DS100149(04/09)
IXTP16N50PM
Symbol
Test Conditions
Characteristic Values
ISOLATED TO-220 (IXTP...M)
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS= 20V, ID = 8A, Note 1
9
16
S
Ciss
Coss
Crss
2480
237
18
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
24
28
70
25
ns
ns
ns
ns
1
2
3
Resistive Switching Times
VGS = 10V, VDS = 0.5 VDSS, ID = 8A
ꢀ
RG = 10Ω (External)
Qg(on)
Qgs
43
15
12
nC
nC
nC
VGS= 10V, VDS = 0.5
ꢀ
VDSS, ID = 8A
Qgd
RthJC
1.66 °C/W
Terminals: 1 - Gate
2 - Drain (Collector)
3 - Source (Emitter)
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
16
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
64
1.5
V
IF = 16A, -di/dt = 100A/μs,
400
ns
VR = 100V, VGS = 0V
Notes:1. Pulse Test, t ≤ 300μs; Duty Cycle, d ≤ 2 %.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or moreof the following U.S. patents: 4,850,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXTP16N50PM
Fig. 1. Output Characteristics
@ 25ºC
Fig. 2. Output Characteristics
@ 125ºC
20
18
16
14
12
10
8
20
18
16
14
12
10
8
VGS = 10V
VGS = 10V
8V
8V
7V
7V
6V
6
6
4
4
6V
5V
2
2
0
0
0
1
2
3
4
5
6
7
8
9
0
2
4
6
8
10
12
14
16
18
20
VDS - Volts
VDS - Volts
Fig. 3. RDS(on) Normalized to ID = 8A Value
vs. Junction Temperature
Fig. 4. RDS(on) Normalized to ID = 8A Value
vs. Drain Current
3.2
2.8
2.4
2.0
1.6
1.2
0.8
0.4
2.8
2.6
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
VGS = 10V
VGS = 10V
TJ = 125ºC
I D = 16A
I D = 8A
TJ = 25ºC
0
2
4
6
8
10
12
14
16
18
20
-50
-25
0
25
50
75
100
125
150
ID - Amperes
TJ - Degrees Centigrade
Fig. 5. Maximum Drain Current vs.
Case Temperature
Fig. 6. Input Admittance
20
18
16
14
12
10
8
8
7
6
5
4
3
2
1
0
TJ = 125ºC
25ºC
- 40ºC
6
4
2
0
-50
-25
0
25
50
75
100
125
150
4.0
4.4
4.8
5.2
5.6
6.0
6.4
6.8
7.2
TJ - Degrees Centigrade
VGS - Volts
© 2009 IXYS CORPORATION, All Rights Reserved
IXTP16N50PM
Fig. 8. Forward Voltage Drop of
Fig. 7. Transconductance
Intrinsic Diode
28
24
20
16
12
8
70
60
50
40
30
20
10
0
TJ = - 40ºC
25ºC
125ºC
TJ = 125ºC
TJ = 25ºC
4
0
0
2
4
6
8
10
12
14
16
18
20
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
ID - Amperes
VSD - Volts
Fig. 9. Gate Charge
Fig. 10. Capacitance
10
9
8
7
6
5
4
3
2
1
0
10,000
1,000
100
10
VDS = 250V
I D = 8A
C
C
I G = 10mA
iss
oss
C
rss
= 1 MHz
5
f
1
0
10
15
20
25
30
35
40
0
5
10
15
20
25
30
35
40
45
VDS - Volts
QG - NanoCoulombs
Fig. 12. Maximum Transient Thermal Impedance
Fig. 11. Forward-Bias Safe Operating Area
10.00
1.00
0.10
0.01
100.0
10.0
1.0
RDS(on) Limit
25µs
100µs
1ms
10ms
DC
TJ = 150ºC
TC = 25ºC
Single Pulse
0.1
0.0001
0.001
0.01
0.1
1
10
10
100
1000
Pulse Width - Seconds
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS REF: F_16N50P(5J)4-30-09-C
