IXTC250N075T
Symbol
gfs
TestConditions
Characteristic Values
ISOPLUS220 (IXTC) Outline
(TJ = 25°C unless otherwise specified)
Min. Typ.
Max.
VDS= 10 V; ID = 60 A, Note 1
75
120
S
Ciss
Coss
Crss
9900
1100
230
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
29
65
55
47
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = 25 A
RG = 3.3 Ω (External)
1.Gate 2. Drain
3.Source
Note: Bottom heatsink (Pin 4) is
electrically isolated from Pins 1,2, and 3.
Qg(on)
Qgs
200
40
nC
nC
nC
VGS= 10 V, VDS = 0.5 VDSS, ID = 25 A
Qgd
50
RthJC
RthCS
0.96 °C/W
°C/W
0.5
Source-Drain Diode
Characteristic Values
TJ = 25°C unless otherwise specified)
Symbol
IS
Test Conditions
Min. Typ.
Max.
VGS = 0 V
220
A
A
ISM
VSD
trr
Pulse width limited by TJM
IF = 25 A, VGS = 0 V, Note 1
600
1.0
V
IF = 25 A, -di/dt = 100 A/μs
90
ns
VR = 40 V, VGS = 0 V
Notes: 1. Pulse test: t ≤ 300 μs, duty cycle d ≤ 2 %;
2. Drain and Source Kelvin contacts must be located less than 5 mm
from the plastic body.
